Fig. 128: Removing Bearing From Counter Shaft
Courtesy of GENERAL MOTORS CORP.
22. Using a hydraulic press or a remover, remove the bearing from the counter shaft, when
necessary.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 129: Tapered Bearing Cup
Courtesy of GENERAL MOTORS CORP.
23. Remove the bearing race from the main shaft.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 130: Main Shaft Assembly
Courtesy of GENERAL MOTORS CORP.
24. In order to remove the main shaft bearing, fasten it to the synchronizer and pull up with one
hand and push down with the other hand.
CLUTCH HOUSING DISASSEMBLE
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 131: Transmission
Courtesy of GENERAL MOTORS CORP.
1. Only some applications require the removal of the clutch housing.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
