Chevrolet Silverado / GMC Sierra. Manual - part 2549
Fig. 116: Speedometer Tracking Balls
Courtesy of GENERAL MOTORS CORP.
8. Using a magnet, remove the pulling sphere out of the speedometer gear.
9. Remove the speedometer gear.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 117: Snap Ring
Courtesy of GENERAL MOTORS CORP.
10. Place the transmission over 2 pieces of wood.
11. Using locking pliers, remove the snap ring from the 5th gear bearing.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 118: Removing Roll Pin And 5th Gear Fork
Courtesy of GENERAL MOTORS CORP.
12. Using a hammer and punch, remove the roll pin and the 5th gear fork.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 119: Synchronizer Ring And 5th Gear
Courtesy of GENERAL MOTORS CORP.
13. Remove the taper and the synchronization ring from the 5th gear.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
