Chevrolet Silverado / GMC Sierra. Manual - part 2543
Fig. 91: Inserts
Courtesy of GENERAL MOTORS CORP.
15. Arrange the inserts.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 92: Removing Fork Pin And Fork
Courtesy of GENERAL MOTORS CORP.
16. Using a punch and a hammer, remove the fork pin and fork, if necessary.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 93: Fork Inserts
Courtesy of GENERAL MOTORS CORP.
17. Remove the fork inserts if they are worn or scored. It may help to use a flat-head
screwdriver.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 94: Removing 3rd And 4th Gear Stop
Courtesy of GENERAL MOTORS CORP.
18. Remove the 3rd and 4th gear stop.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
