Chevrolet Silverado / GMC Sierra. Manual - part 2536
Fig. 62: 2nd Gear Synchronizer Ring
Courtesy of GENERAL MOTORS CORP.
10. Remove the 2nd gear synchronizer ring.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 63: Snap Ring Holding Synchronization Hammer Onto 1st And 2nd Gears
Courtesy of GENERAL MOTORS CORP.
11. Using locking pliers, remove the snap ring from the synchronization hammer on the 1st and
2nd gears.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 64: Removing 1st Gear And Synchronizer
Courtesy of GENERAL MOTORS CORP.
12. Using a bearing press or remover, remove the 1st gear and the synchronizer.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 65: 1st And 2nd Gear Synchronizer
Courtesy of GENERAL MOTORS CORP.
13. Remove the 1st and 2nd gear synchronizer.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
