Chevrolet Silverado / GMC Sierra. Manual - part 2132
Fig. 69: View Of J 33049 Camshaft Bearing Service Kit Components
Courtesy of GENERAL MOTORS CORP.
2. Select the expanding driver (4-8) and washer (2 or 3) from the J 33049 . Refer to Piston
and Connecting Rod Assemble.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
3. Assemble the tool.
Fig. 70: Driving Bearing Out Of Or Into Engine Block
Courtesy of GENERAL MOTORS CORP.
4. Insert the tool (1) through the front of the engine block and into the bearing.
5. Tighten the expander assembly nut until snug.
6. Push the guide cone (2) into the front camshaft bearing in order to align the tool.
7. Drive the bearing into the block bore.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 71: Driving Bearing Out Of Or Into Engine Block
Courtesy of GENERAL MOTORS CORP.
8. Install the front and rear bearings to the block.
CAMSHAFT TIMING CHAIN AND SPROCKET CLEANING AND INSPECTION
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 72: Identifying Timing Chain and Sprockets Inspection Areas
Courtesy of GENERAL MOTORS CORP.
1. Clean the components with cleaning solvent.
CAUTION: Refer to Safety Glasses and Compressed Air Caution .
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
