Fig. 47: Piston Pin, Piston & Connecting Rod 3. Install the piston pin to the piston and connecting rod. 4. Install the retainers. The retainers should be seated in the groove of the pin bore.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 48: Removing/Installing Piston Rings 5. Using piston ring pliers, install the piston rings onto the piston. The dimple or mark on the piston ring should face the top of the piston. If no dimple or mark can be found on the top IMPORTANT: When installing piston rings, use a ring expander plier type tool. Do not roll the rings into the grooves of the piston. Use
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
compression ring, it may be installed in either direction. 6. Position the oil control ring end gaps a minimum of 25 mm (1.0 in) from each other. 7. Position the compression ring end gaps 180 degrees opposite each other. Fig. 49: View Of Piston, Connecting Rod & Bearing Assembly
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
8. Install the connecting rod bearings to the rod and cap. CAMSHAFT BEARING REMOVAL Tools Required J 33049 Camshaft Bearing Service Set Removal Fig. 50: Camshaft Bearings IMPORTANT: A loose camshaft bearing may be caused by an enlarged, out
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
