Tighten: Tighten the oil pump drive shaft clamp bolt to 25 N.m (18 lb ft).
Fig. 708: View Of Ignition Coil Bracket & Bolts
Courtesy of GENERAL MOTORS CORP.
15. If required, install the ignition coil bracket and bolts.
Tighten: Tighten the ignition coil bracket bolts to 12 N.m (106 lb in).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 709: View Of Ignition Coil & Bolts
Courtesy of GENERAL MOTORS CORP.
16. Install the ignition coil and ignition coil bolts.
Tighten: Tighten the ignition coil bolts to 12 N.m (106 lb in).
VALVE ROCKER ARM COVER INSTALLATION - LEFT SIDE
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 710: View Of Rocker Arm Cover And Gasket
Courtesy of GENERAL MOTORS CORP.
1. Install the NEW valve rocker arm cover gasket into the groove of the valve rocker arm
cover.
2. Install the NEW valve rocker arm cover bolt grommets into the valve rocker arm cover.
IMPORTANT: Do not reuse the valve cover gasket or the valve rocker arm
cover bolt grommets.
