Fig. 161: View Of Engine Ground Strap & Bolt
Courtesy of GENERAL MOTORS CORP.
51. Position the engine ground strap to the cylinder head and cowl.
52. Install the engine ground strap bolt to the rear of the left cylinder head and cowl.
Tighten: Tighten the bolt to 16 N.m (12 lb ft).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 162: View Of Engine Harness Electrical Connectors & Inlet Hose Clamp
Courtesy of GENERAL MOTORS CORP.
53. Connect the engine harness electrical connector (1) to the oil pressure sensor.
54. Connect the engine harness electrical connector (2) to the lifter oil manifold.
55. Install the heater hoses. Refer to Heater Inlet Hose Replacement (Non-HP2) and Heater
Outlet Hose Replacement .
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 163: View Of Radiator Outlet Hose
Courtesy of GENERAL MOTORS CORP.
56. Install the radiator outlet hose to the water pump.
57. Position the radiator outlet hose clamp at the water pump.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 164: View Of Radiator Vent Inlet Hose Clamp At Water Pump
Courtesy of GENERAL MOTORS CORP.
58. Install the radiator inlet hose to the water pump.
59. Position the radiator inlet hose clamp (3) at the water pump.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
