Chevrolet Silverado / GMC Sierra. Manual - part 2039
Fig. 33: View Of Crankshaft Sprocket
Courtesy of GENERAL MOTORS CORP.
11. Remove the crankshaft sprocket (207).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 34: View Of Crankshaft Key & Keyway
Courtesy of GENERAL MOTORS CORP.
12. Remove the crankshaft sprocket key, if required.
Installation Procedure
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 35: View Of Crankshaft Key & Keyway
Courtesy of GENERAL MOTORS CORP.
1. Install the key into the crankshaft keyway, if previously removed.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 36: View Of Installed Crankshaft Key
Courtesy of GENERAL MOTORS CORP.
2. Tap the key (122) into the keyway until both ends of the key bottom onto the crankshaft.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
