Chevrolet Silverado / GMC Sierra. Manual - part 2026
Fig. 456: View Of Oil Cooler Line Clip & Bolt
Courtesy of GENERAL MOTORS CORP.
12. Position the transmission oil cooler line clip and install the bolt to the oil pan.
Tighten: Tighten the bolt to 9 N.m (80 lb in).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 457: View Of Oil Cooler Line Clip
Courtesy of GENERAL MOTORS CORP.
13. For vehicles with a 6L80-E automatic transmission, install the oil cooler lines to the clip
(1).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 458: View Of Oil Cooler Line Clip
Courtesy of GENERAL MOTORS CORP.
14. For vehicles with a 4L80-E automatic transmission, install the oil cooler lines to the clip
(1), if equipped.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 459: View Of Oil Cooler Line Clip
Courtesy of GENERAL MOTORS CORP.
15. For vehicles with a 4L60-E/4L70-E automatic transmission, install the oil cooler lines to the
clip (1), if equipped.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
