Fig. 398: View Of Lower Transmission Bolt
Courtesy of GENERAL MOTORS CORP.
19. For vehicles with a 6L80-E automatic transmission, remove the lower left transmission bolt.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 399: View Of Lower Transmission Stud
Courtesy of GENERAL MOTORS CORP.
20. For vehicles with a 6L80-E automatic transmission, remove the lower right transmission
stud.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 400: View Of Electrical Connectors & Clips
Courtesy of GENERAL MOTORS CORP.
21. Disconnect the engine harness electrical connector (4) from the oil level sensor.
22. Remove the engine harness clip (3) from the transmission oil cooler line bracket.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 401: View Of Electrical Connector, Cable Channel Bolt & Pin
Courtesy of GENERAL MOTORS CORP.
23. Remove the battery cable channel bolt (2).
24. Slide the channel pin (3) out of the oil pan tab.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
