Chevrolet Silverado / GMC Sierra. Manual - part 1992
3. Install the CMP actuator magnet bolts (751).
Tighten: Tighten the bolts to 12 N.m (106 lb in).
4. Connect the engine harness electrical connector to the CMP actuator magnet.
5. Install the water pump. Refer to Water Pump Replacement (LY6, L76 and L92) or
Water Pump Replacement (LH6, LY2, LY5, and LMG) .
ENGINE FRONT COVER REPLACEMENT (LC9, LH6, LMG, LY2 AND LY5)
Tools Required
J 41476 Front and Rear Cover Alignment Tool. See Special Tools .
Removal Procedure
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 330: View Of Electrical Connector, Cable Channel Bolt & Pin
Courtesy of GENERAL MOTORS CORP.
1. Remove the water pump. Refer to Water Pump Replacement (LY6, L76 and L92) or
Water Pump Replacement (LH6, LY2, LY5, and LMG) .
2. Remove the crankshaft balancer. Refer to Crankshaft Balancer Replacement.
3. Disconnect the engine harness electrical connector (1) from the camshaft position (CMP)
sensor wire harness electrical connector.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 331: View Of Oil Pan-To-Front Cover Bolts
Courtesy of GENERAL MOTORS CORP.
4. Remove the oil pan-to-front cover bolts (1).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 332: View Of Front Cover & Gasket
Courtesy of GENERAL MOTORS CORP.
5. Remove the front cover bolts (1).
6. Remove the front cover (2) and gasket (3).
7. Discard the front cover gasket.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
