Chevrolet Silverado / GMC Sierra. Manual - part 1980
Fig. 291: View Of Battery Cable Terminals & Stud
Courtesy of GENERAL MOTORS CORP.
9. Ensure that the engine harness terminal (3) is positioned behind the negative battery cable
terminal (2).
10. Position the negative battery cable terminal (2) to the cylinder head.
11. Install the negative battery cable stud (1) to the front of the right cylinder head.
Tighten: Tighten the stud to 25 N.m (18 lb ft).
12. Install the pushrods. Refer to Valve Rocker Arm and Push Rod Replacement.
13. Install the right exhaust manifold. Refer to Exhaust Manifold Replacement - Right Side
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
(4.8L, 5.3L, 6.0L, and 6.2L)
14. Install the coolant air bleed pipe. Refer to Coolant Air Bleed Pipe Assembly
Replacement (LH6, LY5, LMG, L76, L92) or Coolant Air Bleed Pipe Assembly
Replacement (LY2, LY6) .
15. Install the intake manifold. Refer to Intake Manifold Replacement (L92 - First Design)
or Intake Manifold Replacement (L92 - Second Design) or Intake Manifold
Replacement (LY2 and LY6) or Intake Manifold Replacement (LH6, LMG, LY5 and
L76).
16. Install the oil level indicator. Refer to Oil Level Indicator and Tube Replacement.
VALVE LIFTER REPLACEMENT (L92 - FIRST DESIGN)
Removal Procedure
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 292: View Of Lifter Guides & Lifters
Courtesy of GENERAL MOTORS CORP.
1. Remove the cylinder head and gasket. Refer to Cylinder Head Replacement - Left Side
or Cylinder Head Replacement - Right Side.
2. Remove the valve lifter guide bolts (211).
3. Remove the valve lifter guides (210) with the lifters. Note the installed position of the
guides. The notched area of the guides is to align with the locating tab on the engine block.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 293: Exploded View Of Lifter Guides & Lifters
Courtesy of GENERAL MOTORS CORP.
4. Remove the valve lifters (209, 219) from the guide (210).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
