Fig. 212: Removing/Installing Engine Valley Cover 1. Remove the intake manifold. Refer to Intake Manifold Replacement (L92 - First Design) or Intake Manifold Replacement (L92 - Second Design) or Intake Manifold
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Replacement (LY2 and LY6) or Intake Manifold Replacement (LH6, LMG, LY5 and 2. Remove the engine valley cover bolts (506). 3. Remove the engine valley cover (555) and gasket (556). 4. Remove the O-ring seals (537) from the cover. Fig. 213: Removing/Installing Oil Pressure Sensor & Washer 5. Remove the oil pressure sensor (706) and washer (707). Installation Procedure IMPORTANT: All gasket surfaces should be free of oil or other foreign material during assembly.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 214: Removing/Installing Oil Pressure Sensor & Washer 1. Apply sealant GM P/N 12346004 (Canadian P/N 10953480) or equivalent, to the threads of the oil pressure sensor. 2. Install a NEW washer (707) and the oil pressure sensor (706). Tighten: Tighten the sensor to 35 N.m (26 lb ft). NOTE: Refer to Fastener Notice .
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 215: Removing/Installing Engine Valley Cover 3. Lubricate the O-ring seals with clean engine oil. 4. Install the O-ring seals (537) to the cover.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
