Chevrolet Silverado / GMC Sierra. Manual - part 1831
Fig. 148: View Of Front HO2S, Electrical Connector & CPA Retainer
Courtesy of GENERAL MOTORS CORP.
8. Connect the engine wiring harness electrical connector (2) to the left front HO2S (1)
electrical connector.
9. Install the CPA retainer (3) to the left front HO2S.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Exhaust - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 149: View Of Exhaust Muffler, Exhaust Manifold Pipe, Gasket & Nuts
Courtesy of GENERAL MOTORS CORP.
10. Tighten the exhaust muffler clamp (3).
Tighten: Tighten the clamp to 47 N.m (35 lb ft).
11. Install any necessary exhaust muffler insulators that were separated from the muffler.
12. Remove the jack stand from under the muffler.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Exhaust - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 150: View Of Transmission Support Crossmember & Bolts
Courtesy of GENERAL MOTORS CORP.
13. Position the transmission support crossmember.
14. Install the transmission support crossmember bolts.
Tighten: Tighten the bolts to 95 N.m (70 lb ft).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Exhaust - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 151: Identifying Transmission Mount Nuts
Courtesy of GENERAL MOTORS CORP.
15. Using the transmission jack, lower the transmission onto the transmission support.
16. Install the transmission mount to transmission support nuts.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Exhaust - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
