Fig. 559: View Of Oil Pump Cover Bolts
Courtesy of GENERAL MOTORS CORP.
3. Remove the oil pump cover bolts.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 560: View Of Oil Pump Cover
Courtesy of GENERAL MOTORS CORP.
4. Remove the oil pump cover.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 561: View Of Oil Pump Drive Gear & Driven Gear
Courtesy of GENERAL MOTORS CORP.
5. Remove the oil pump drive gear and the oil pump driven gear.
6. Matchmark the gear teeth for assembly.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 562: View Of Oil Pump Pressure Relief Valve, Spring & Spring Straight Pin
Courtesy of GENERAL MOTORS CORP.
7. Remove the following items:
1. The oil pump pressure relief valve spring straight pin
2. The oil pump pressure relief spring
3. The oil pump pressure relief valve
OIL PUMP CLEANING AND INSPECTION
CAUTION: Refer to SAFETY GLASSES CAUTION .
