4. Remove the differential side bearings using the J 22888-20A . See Special Tools. Installation Procedure Fig. 191: Driving Differential Side Bearing Into Position
2008 Chevrolet Silverado 1500 2008 Driveline/Axle Rear Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
1. For the 8.6 inch, the 9.5 inch, and the 10.5 inch axles, install the differential side bearings by doing the following: 1. In order to protect the differential case, install theJ 8107-4 , 8. See Special Tools.6 inch axle, or the J 36597 , 9.5 inch or 10.5 inch axles, in the case on the side opposite 2. Install the J 21784 , 8. See Special Tools.6 inch axle, or the J 29710 , 9.5 inch or 10.5 inch axles (2), and the J 8092 (1) onto the differential case bearing as shown. 3. Drive the bearing onto the case using the J 21784 or the J 29710 and the J 8092 . See Special Tools.
2008 Chevrolet Silverado 1500 2008 Driveline/Axle Rear Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 192: Installing Differential Side Bearings (11.5 Inch Axles) 2. For the 11.5 inch axle, install the differential side bearings by doing the following: 1. In order to protect the differential case, install the J 8107-5 in the case on the side
2008 Chevrolet Silverado 1500 2008 Driveline/Axle Rear Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
opposite the bearing installation. 2. Install the J 44420 (2) and the J 8092 (1) onto the differential case bearing as shown. See Special Tools. 3. Drive the bearing onto the case using the J 44420 and the J 8092 . See Special Tools. 3. Install the differential assembly. Refer to Differential Replacement (8.6, 9.5/9.5LD Inch Axles) or Differential Replacement (10.5 Inch, 11.5 Inch Axle). REAR AXLE REPLACEMENT (15 SERIES WITH DRUM BRAKES) Removal Procedure
2008 Chevrolet Silverado 1500 2008 Driveline/Axle Rear Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
