Fig. 103: Driving Inner Bearing Cup Into Wheel Hub
Courtesy of GENERAL MOTORS CORP.
9. Drive the inner bearing cup into the wheel hub using the J 24427 (2) and the J 8092 (1).
See Special Tools.
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Rear Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 104: Inner Hub Bearing
Courtesy of GENERAL MOTORS CORP.
10. Install the inner bearing.
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Rear Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 105: J 8092 & J 44420
Courtesy of GENERAL MOTORS CORP.
11. Using the J 44420 (2) and the J 8092 (1), install the new oil seal. Ensure the seal is fully
seated in the hub bore.
12. Install the rotor, if necessary. Refer to Rear Brake Rotor Replacement (JD9) or Rear
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Rear Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Brake Rotor Replacement (JH6) or Rear Brake Rotor Replacement (JH7) .
13. Apply a light coat of high melting point EP bearing lubricant to the axle housing spindle.
Fig. 106: Wheel Hub & Axle Housing
Courtesy of GENERAL MOTORS CORP.
14. Install the wheel hub to the axle housing.
IMPORTANT: If the wheel hub assembly does not fully seat itself onto the
axle shaft spindle and is removed, the wheel hub seal must
be replaced.
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Rear Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
