Fig. 151: Differential Bearing Adjuster Nuts & Bearing Cups
Courtesy of GENERAL MOTORS CORP.
26. Remove the right side differential bearing adjuster by doing the following:
1. Install the J 36599-A onto the differential bearing adjuster nut. See Special Tools.
2. Turn the J 36599-A clockwise in order to push the bearing cup out of the bore. See
Special Tools.
27. Remove the right side differential bearing adjuster nut sleeve using a hammer and brass
drift.
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 152: Holding Pinion Flange Using Special Tool
Courtesy of GENERAL MOTORS CORP.
28. Install the J 8614-01 as shown. See Special Tools.
Remove the pinion nut while holding the J 8614-01 . See Special Tools.
29. Remove the washer.
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 153: View Of Pinion Yoke
Courtesy of GENERAL MOTORS CORP.
30. Install the J 8614-2 (2) and the J 8614-3 (3) into the J 8614-01 (1) as shown. See Special
Tools.
31. Remove the pinion yoke by turning the J 8614-3 (3) clockwise while holding the J 8614-01
(1). See Special Tools.
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 154: Installing J 45765 To Left Side Differential Carrier Case (9.25 Inch Axle)
Courtesy of GENERAL MOTORS CORP.
32. Install the J 45765 to the left side differential carrier case half over the drive pinion as
shown. See Special Tools.
33. Turn the forcing screw of the J 45765 clockwise to remove the following components from
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
