Chevrolet Silverado / GMC Sierra. Manual - part 1190
2nd Clutch
25
2nd Clutch
26
C.C. Signal
26
C.C. Signal
27
3-4 Signal
27
3-4 Signal
27/29
3-4 Signal
27/29
3-4 Signal
28
3rd Accumulator
29/28
3-4 Clutch/3rd Accumulator
29/28
3-4 Clutch/3rd Accumulator
29
3-4 Clutch
29
3-4 Clutch
29
3-4 Clutch
29
3-4 Clutch
29
3-4 Clutch
30
4th Signal
30
4th Signal
31
Servo Feed
31
Servo Feed
31
Servo Feed
32
4th
33
3-4 Accumulator
33
3-4 Accumulator
33
3-4 Accumulator
34a
D3 - Blocked on M33 Models
34a
D3 - Blocked on M33 Models
34
D3
34
D3
34
D3
34
D3
34
D3
34
D3
35a
Overrun- Blocked on M33 Models
35a
Overrun- Blocked on M33 Models
35
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Overrun
35/36
Overrun/Overrun Clutch Feed
35/36
Overrun/Overrun Clutch Feed
35/39
Overrun/Orificed D2
36
Overrun Clutch Feed
37
Overrun Clutch
38a
D2 - M33 Models Only
38a
D2 - M33 Models Only
38
D2
38
D2
38
D2
38
D2
38
D2
38
D2
38/39
D2/Orificed D2
41
Lo
41
Lo
41
Lo
41
Lo
42
Lo/1st
42
Lo/1st
43
Exhaust
43/44
Exhaust/Orificed Exhaust
43/44
Exhaust/Orificed Exhaust
44
Orificed Exhaust
47
Void
48
Regulated Apply
48
Regulated Apply
49
Shift Solenoids Screen
50
Pressure Control Solenoid Screen
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 566: Spacer Plate to Control Valve Body Gasket
Courtesy of GENERAL MOTORS CORP.
Callout
Component Name
3
Line
3
Line
3
Line
9
Actuator Feed Limit
9
Actuator Feed Limit
9
Actuator Feed Limit
9
Actuator Feed Limit
9
Actuator Feed Limit
9
Actuator Feed Limit
9
Actuator Feed Limit
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
9
Actuator Feed Limit
9
Actuator Feed Limit
10
Filtered Actuator Feed
10
Filtered Actuator Feed
10
Filtered Actuator Feed
10
Filtered Actuator Feed
11
Torque Signal
11
Torque Signal
11
Torque Signal
12
PR
12
PR
12
PR
12
PR
12
PR
13
D4-3-2
13
D4-3-2
14
Lo/Reverse
14
Lo/Reverse
14
Lo/Reverse
15
Reverse
15
Reverse
15
Reverse
16
Reverse Input (Rev. Cl.)
17
D4
17
D4
17
D4
17
D4
17
D4
17
D4
18
Forward Clutch Feed
18
Forward Clutch Feed
18
Forward Clutch Feed
20
Accumulator
20
Accumulator
20
Accumulator
