Removal
Fig. 374: View Of Fan, Water Pump Pulley & Bolts
Courtesy of GENERAL MOTORS CORP.
1. Remove the bolts and the fan and water pump pulley using the J 41240 . See Special Tools.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 375: View Of Water Pump Inlet Hose & Clamps
Courtesy of GENERAL MOTORS CORP.
2. Remove the clamps and the water pump inlet hose.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 376: View Of Water Pump & Bolts
Courtesy of GENERAL MOTORS CORP.
3. Remove the water pump bolts.
4. Remove the water pump.
5. Remove the water pump gaskets.
6. Discard the water pump gaskets.
CRANKSHAFT BALANCER REMOVAL
Tools Required
J 23523-F Balancer Remover and Installer
Removal
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
