Fig. 40: View Of Steering Cable Retainer On Steering Column 8. Install the retainer securing the cable to the steering column. 9. Position the carpet and insulation around the driver's area. 10. Install the drivers seat. Refer to Front Seat Replacement - Bucket .
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
11. Install the instrument panel knee bolster. Refer to Knee Bolster Replacement (with RPO SLT) or Knee Bolster Replacement (without RPO SLT) . 12. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Fig. 41: View Of Range Selector Cable End At Transmission Range Selector Lever 13. Align and install the cable to the bracket. 14. Install the range selector cable end (2) to the transmission range selector lever ball stud (1). 15. Install the cable clip on the transfer case, if equipped.
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 42: View Of Retainer Securing Cable To Bracket 16. Install the retainer that secures the cable to the bracket.
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 43: View Of Clips On Cable From Floor Panel Reinforcement 17. Install the clips on the cable to the floor panel reinforcement. 18. Lower the vehicle. 19. Test the transmission for proper shift operation. 20. If all of the gear positions cannot be achieved, adjust the cable. Refer to Range Selector Lever Cable Adjustment. RANGE SELECTOR LEVER CABLE ADJUSTMENT
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - 4L60-E/4L65-E/4L70-E - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
