Chevrolet Silverado / GMC Sierra. Manual - part 88
Fig. 279: Manual Transmission Bolts
Courtesy of GENERAL MOTORS CORP.
14. Install the manual transmission bolts, if equipped.
Tighten: Tighten the bolts to 50 N.m (37 lb ft).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 280: Engine Wire Harness Bracket Bolts
Courtesy of GENERAL MOTORS CORP.
15. Install two engine wire harness bracket bolts (1).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 281: Transmission Tube Bracket
Courtesy of GENERAL MOTORS CORP.
16. Install the engine harness and transmission tube bracket bolt (1).
Tighten: Tighten the bolt to 9 N.m (80 lb in).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 282: View Of Oil Level Sensor Electrical Connector, CKP Electrical Connector
& Battery Ground Bolt
Courtesy of GENERAL MOTORS CORP.
17. Install the starter. Refer to Starter Motor Replacement (4.3L) .
18. Connect the oil level sensor electrical connector (7).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
