Tighten: Tighten the adapter to 55 N.m (41 lb ft).
3. Install the oil filter.
Tighten: Tighten the filter to 30 N.m (22 lb ft).
4. Lower the vehicle.
5. Fill the engine with the proper quantity and quality of engine oil. Refer to Approximate
Fluid Capacities .
OIL FILTER BYPASS VALVE REPLACEMENT
Removal Procedure
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 252: View Of Oil Filter
Courtesy of GENERAL MOTORS CORP.
1. Raise and suitably support the vehicle. Refer to Lifting and Jacking the Vehicle .
2. Position a suitable container under the vehicle to catch the oil.
3. Remove the oil filter.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 253: View Of Oil Filter Bypass Valve
Courtesy of GENERAL MOTORS CORP.
4. Using a suitable prying tool, remove the oil filter bypass valve.
5. Clean and inspect the valve bore for damage.
Installation Procedure
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 254: View Of Oil Filter Bypass Valve
Courtesy of GENERAL MOTORS CORP.
1. Install a NEW oil filter bypass valve using the following procedure:
1. Use a brass drift that is the same diameter as the outside diameter of the oil filter
bypass valve.
2. Install the oil filter bypass valve into the oil gallery bore until slightly below flush with
the surface of the engine block.
3. Using a pointed punch, stake the engine block area around the oil filter bypass valve.
