Chevrolet Silverado / GMC Sierra. Manual - part 45
Tighten: Tighten the bolt to 9 N.m (80 lb in).
Fig. 122: View Of Engine Wiring Harness Bracket & Nuts
Courtesy of GENERAL MOTORS CORP.
10. Install the engine wiring harness bracket.
11. Install the engine wiring harness bracket nuts.
Tighten: Tighten the nuts to 12 N.m (106 lb in).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
VALVE ROCKER ARM COVER REPLACEMENT - RIGHT SIDE
Removal Procedure
Fig. 123: View Of Air Cleaner Outlet Duct Clamp
Courtesy of GENERAL MOTORS CORP.
1. Loosen the air cleaner outlet duct clamp at the mass airflow (MAF)/intake air temperature
(IAT) sensor.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 124: Identifying PCV Hose
Courtesy of GENERAL MOTORS CORP.
2. Remove the positive crankcase ventilation (PCV) hose.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
