Chevrolet Silverado / GMC Sierra. Manual - part 25
Fig. 43: View Of A/C Pressure Switch & Compressor Clutch Connectors
Courtesy of GENERAL MOTORS CORP.
1. Remove the fuel pipes/hoses. Refer to Fuel Hose/Pipes Replacement - Engine
Compartment .
2. Disconnect the following electrical connectors:
The A/C pressure switch (1), if equipped
The air conditioning (A/C) compressor clutch (2), if equipped
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 44: Control Port Injector Module
Courtesy of GENERAL MOTORS CORP.
3. Disconnect the control port injector module (1).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
Fig. 45: View Of Engine Wiring Harness Clips
Courtesy of GENERAL MOTORS CORP.
4. Remove the engine wiring harness clips (1, 2) from the engine harness brackets.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
