47– 56 47 Back Door Opener Switch Assembly Removal 1. Turn off all the electrical equipment and ignition switch. ). 4. Remove the back door upper trim board assembly ( ). 5. Remove the back door opener switch assembly. a. Disconnect the back door opener switch connector (arrow). b. Remove 2 fixing bolts from the back door opener switch assembly, and remove the back door opener (Tightening torque: 10 ± 1 N·m) Installation Installation is in the reverse order of removal. CAUTION Be sure to wear safety equipment to prevent accidents when removing back door opener switch assembly. Try to prevent body paint surface from being scratched when removing back door opener switch assembly. RT21370261 RT21370300 CAUTION Make sure damaged clips are replaced and back door opener switch assembly is installed in place when installing back door opener switch assembly. Install connector in place when installing back door opener switch assembly. |
