Chery Tiggo 5 (T21). Manual - part 460

43–

20

43

a. Turn ignition switch to LOCK.
b. Disconnect the negative battery cable.
c. Disconnect the body wire harness connectors B-044 and

B-040.

d. Using a digital multimeter, check for continuity between

body wire harness connectors B-044 and B-040
according to the table below.

e. Disconnect the body wire harness connectors B-047 and

B-041.

f. Using a digital multimeter, check for continuity between

body wire harness connectors B-047 and B-041
according to the table below.

g. Disconnect the body wire harness connector B-040 and

ground B-036.

h. Using a digital multimeter, check for continuity between

body wire harness connector B-040 and ground B-036
according to the table below.

-

+

RT21430550

D1

D6 D7 D8 D9 D10 D11D12

D2 D3

D4 D5

B-044

1

4

7 10 13 16

2

5

8 11 14 17

3

6

9 12 15 18

B-040

Multimeter

Connection

Condition

Specified

Condition

B-044 (D1) -

B-040 (11)

Always

Continuity

B-044 (D2) -

B-040 (8)

Always

Continuity

-

+

RT21430560

1

4

7

10

13

16

2

5

8

11

14

17

3

6

9

12

15

18

B-041

B1 B2 B3 B4 B5 B6 B7 B8 B9 B10 B11 B12 B13 B14 B15 B16

B17 B18 B19 B20 B21 B22 B23 B24 B25 B26 B27 B28 B29 B30 B31 B32

B-047

Multimeter

Connection

Condition

Specified

Condition

B-047 (B9) -

B-041 (8)

Always

Continuity

-

+

RT21430660

1

4

7 10 13 16

2

5

8 11 14 17

3

6

9 12 15 18

B-040

B-036

Multimeter

Connection

Condition

Specified

Condition

B-040 (3) - B-036

Always

Continuity

Repair or replace body wire harness and
connector

NG

43–

21

43

a. Turn ignition switch to LOCK.
b. Disconnect the negative battery cable.
c. Disconnect the front left door wire harness connectors



F-007 and F-006 (a).

d. Using a digital multimeter, check for continuity between

front left door wire harness connectors F-007 and F-006
(a) according to the table below.

e. Disconnect the front left door wire harness connectors



F-007 and F-009.

f. Using a digital multimeter, check for continuity between

front left door wire harness connectors F-007 and F-009
according to the table below.

a. Connect all connectors.
b. Connect the negative battery cable.
c. Turn ignition switch to ON.
d. Use X-431 3G diagnostic tester (the latest software) to record and clear DTCs stored in the Body Control

Module (BCM).

e. Turn ignition switch to LOCK and wait for a few seconds.

4

Check front left door wire harness and connector

OK

-

+

RT21430700

1

1

2

2

3

3

4 5 6

7 8 9

10 11 12

13 14 15

16

4

7

10

13

16

17

5

8

11

14

17

18

6

9

12

15

18

F-007

1

2

F-006(a)

Multimeter

Connection

Condition

Specified

Condition

F-007 (8) -

F-006 (a) (1)

Always

Continuity

F-007 (11) -

F-006 (a) (2)

Always

Continuity

-

+

RT21430710

1

1

2

2

3

3

4 5 6

7 8 9

10 11 12

13 14 15

16

4

7

10

13

16

17

5

8

11

14

17

18

6

9

12

15

18

F-007

1

2

3

4

5

6

7

8

16

15

14

13

12

11

10

9

F-009

Multimeter

Connection

Condition

Specified

Condition

F-007 (3) -

F-009 (8)

Always

Continuity

F-007 (8) -

F-009 (6)

Always

Continuity

Repair or replace front left door wire
harness and connector

NG

5

Reconfirm DTCs

OK

43–

22

43

f. Turn ignition switch to ON.
g. Use X-431 3G diagnostic tester (the latest software) to read DTCs stored in the Body Control Module

(BCM) again.

Result

Proceed to

DTC B100C13, B100C71, B100D13 and B100D71
are output

NG

No DTC is output

OK

Replace Body Control Module (BCM)

NG

System is normal

OK

43–

23

43

DTC

B100E13 FR Window Up Control Circuit Circuit Open

DTC

B100E71 FR Window Up Control Circuit Actuator Stuck

DTC

B100F13 FR Window Down Control Circuit Circuit Open

DTC

B100F71 FR Window Down Control Circuit Actuator Stuck
