Chery Tiggo 5 (T21). Manual - part 407

36–

11

36

3

Customer problem analysis

4

Check for DTCs (current DTC and history DTC)

NEXT

For current DTC, go to step 6

For history DTC, go to step 7

DTC
occurs

No



DTC

5

Problem repair (no DTC), then go to step 8

6

Troubleshoot according to Diagnostic Trouble Code (DTC) chart, then go to step 8

7

Troubleshoot according to Problem Symptoms Table, then go to step 8

8

Adjust, repair or replace

9

Conduct test and confirm malfunction has repaired

10

End

NEXT

NEXT

NEXT

NEXT

NEXT

36–

12

36

Diagnostic Trouble Code (DTC) Chart

DTC Code

DTC Definition

B101471

Front Wiper Lo Control Circuit Actuator Stuck

B101571

Front Wiper HI Control Circuit Actuator Stuck

B101671

Rear Wiper Control Circuit Actuator Stuck

B101713

Front Washer Control Circuit Circuit Open

B101771

Front Washer Control Circuit Actuator Stuck

B101813

Rear Washer Control Circuit Circuit Open

B101871

Rear Washer Control Circuit Actuator Stuck

36–

13

36

Self-diagnosis Detection Logic

DTC

B101471 Front Wiper Lo Control Circuit Actuator Stuck

DTC

B101571 Front Wiper HI Control Circuit Actuator Stuck

DTC

B101671 Rear Wiper Control Circuit Actuator Stuck

DTC

B101713 Front Washer Control Circuit Circuit Open

DTC

B101771 Front Washer Control Circuit Actuator Stuck

DTC

B101813 Rear Washer Control Circuit Circuit Open

DTC

B101871 Rear Washer Control Circuit Actuator Stuck

DTC Code

DTC Definition

DTC Detection

Condition

Warning Light

Condition

Possible Cause

B101471

Front Wiper Lo Control
Circuit Actuator Stuck

Ignition switch ON

ON

 Wiper switch

assembly

 Front wiper motor

assembly

 Front washer pump
 Rear wiper motor

assembly

 Rear washer pump
 Wire harness or

connector

 Body Control

Module (BCM)

B101571

Front Wiper HI Control
Circuit Actuator Stuck

B101671

Rear Wiper Control
Circuit Actuator Stuck

B101713

Front Washer Control
Circuit Circuit Open

B101771

Front Washer Control
Circuit Actuator Stuck

B101813

Rear Washer Control
Circuit Circuit Open

B101871

Rear Washer Control
Circuit Actuator Stuck

CAUTION

 When performing circuit diagnosis and test, always refer to circuit diagram for specific circuit and

component information.

36–

14

36

Diagnosis Procedure

a. Remove the wiper switch assembly from malfunctioning vehicle, and install it to a new vehicle to perform a

test.

a. Remove the front wiper motor assembly from malfunctioning vehicle, and install it to a new vehicle to

perform a test.

a. Remove the rear wiper motor assembly from malfunctioning vehicle, and install it to a new vehicle to

perform a test.

a. Remove the front washer pump from malfunctioning vehicle, and install it to a new vehicle to perform a

test.

a. Remove the rear washer pump from malfunctioning vehicle, and install it to a new vehicle to perform a test.

1

Check wiper switch assembly

Replace wiper switch assembly

NG

2

Check front wiper motor assembly

OK

Replace front wiper motor assembly

NG

3

Check rear wiper motor assembly

OK

Replace rear wiper motor assembly

NG

4

Check front washer pump

OK

Replace front washer pump

NG

5

Check rear washer pump

OK

Replace rear washer pump

NG

OK
