30– 20 30 a. Disconnect instrument panel fuse and relay box connector I-007. b. Check wire harness between connector terminals. Check for Open Check for Short a. Disconnect EPS connector E-077. ground point E-081. 5 Check wire harness and connector (EPS - instrument panel fuse and relay box) 1 2 3 4 5 6 7 8 9 10 11 12 13 85 85 87 87 30 87 30 30 86 86 85 86 14 15 16 17 18 19 20 21 22 23 24 25 27 26 I-007 I-057 B1 B2 B3 B4 B5 B6 B7 B8 B9 B10 RT21305005 - + Multimeter Connection Specified Condition I-007 (7) - I-057 (B1) Continuity Multimeter Connection Specified Condition I-007 (7) - Body ground No continuity Repair or replace wire harness or NG Repair or replace instrument panel fuse and relay box or wire harness (instrument panel fuse and 6 Check EPS ground circuit OK E-081 E-077 A1 A2 RT21305003 - + Multimeter Connection Condition Specified Condition E-077 (A2) - E-081 Always Continuity Repair or replace wire harness or NG OK |
