26– 15 26 b. Remove the coupling nuts (arrow) between brake fluid reservoir assembly and body. (Tightening torque: 9 ± 1 N·m) c. Loosen the brake fluid tube fixing clamp (arrow) and disengage the brake fluid tube from brake fluid d. Remove the brake fluid reservoir assembly. Installation Installation is in the reverse order of removal. HINT: RT21260080 RT21260090 |
