Chery Tiggo 5 (T21). Manual - part 280





25–

53

25

a. Turn ignition switch to LOCK.
b. Disconnect the negative battery cable.
c. Disconnect the ABS control module assembly connector

E-085.

d. Disconnect the rear right wheel speed sensor connector

B-009.

e. Using a digital multimeter, check for continuity between

the terminals of connector E-085 and connector B-009 to
check if there is an open in the wire harness and
connector according to the table below.
Standard Condition

f. Disconnect the engine compartment wire harness

connector E-029 and body wire harness connector B-054.

g. Using a digital multimeter, check for continuity between

the terminals of connector E-085 and connector E-029 to
check if there is an open in the wire harness and
connector according to the table below.
Standard Condition

5

Check wire harness and connector (rear right wheel speed sensor - ABS control module
assembly)

RT21250340

E-085

13

12 11 10 9 8 7 6 5 4 3 2

24 23 22 21 20 19 18 17 16 15 14

37 36 35 34 33 32 31 30 29 28 27 26

1

38

25

-

+

2

1

B-009

Multimeter

Connection

Terminal

Condition

Specified

Condition

E-085 (29) -

B-009 (1)

Always

Continuity

E-085 (17) -

B-009 (2)

Always

Continuity

E-085 (17) -

B-009 (1)

Always

No continuity

E-085 (29) -

B-009 (2)

Always

No continuity

B-009 (1) -

B-009 (2)

Always

No continuity

E-085 (17) -

E-085 (29)

Always

No continuity

RT21250350

E-085

13

12 11 10 9 8 7 6 5 4 3 2

24 23 22 21 20 19 18 17 16 15 14

37 36 35 34 33 32 31 30 29 28 27 26

1

38

25

-

+

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

E-029

Multimeter

Connection

Terminal

Condition

Specified

Condition

E-085 (17) -

E-029 (1)

Always

Continuity

E-085 (29) -

E-029 (2)

Always

Continuity

25–

54

25

h. Using a digital multimeter, check for continuity between

the terminals of connector B-054 and connector B-009 to
check if there is an open in the wire harness and
connector according to the table below.
Standard Condition

i. Using a digital multimeter, check for continuity between

connector E-085 and body ground to check if the rear
right wheel speed sensor is short to ground according to
the table below.
Standard Condition

j. Connect the negative battery cable.
k. Turn ignition switch ON.
l. Using a digital multimeter, measure the voltage between

connector E-085 and body ground to check if the rear
right wheel speed sensor is short to power supply
according to the table below.
Standard Condition

RT21250360

-

+

2

1

B-009

1

2

3

4

5

6

7

8

9 10 11

12 13 14 15 16 17 18 19 20 21 22

B-054

Multimeter

Connection

Terminal

Condition

Specified

Condition

B-009 (1) - B-054

(2)

Always

Continuity

B-009 (2) - B-054

(1)

Always

Continuity

RT21250370

E-085

13

12 11 10 9 8 7 6 5 4 3 2

24 23 22 21 20 19 18 17 16 15 14

37 36 35 34 33 32 31 30 29 28 27 26

1

38

25

-

+

Multimeter

Connection

Terminal

Condition

Specified

Condition

E-085 (17) - Body

ground

Always

No continuity

E-085 (29) - Body

ground

Always

No continuity

RT21250380

E-085

13

12 11 10 9 8 7 6 5 4 3 2

24 23 22 21 20 19 18 17 16 15 14

37 36 35 34 33 32 31 30 29 28 27 26

1

38

25

-

+

V

Multimeter

Connection

Terminal

Condition

Specified

Condition

E-085 (17) - Body

ground

Ignition switch ON Approximately 0 V

E-085 (29) - Body

ground

Ignition switch ON Approximately 0 V

25–

55

25

a. Use X-431 3G diagnostic tester to clear the DTC.
b. Start the engine.
c. Drive the vehicle at 15 km/h or more, read the ABS control module assembly DTC again with X-431 3G

diagnostic tester.

d. Check if the same DTC is output.

Repair or replace wire harness and
connector between rear right wheel speed
sensor and ABS control module assembly

NG

6

Reconfirm DTCs

OK

System operates normally

NO

Replace ABS control module assembly

YES

25–

56

25

DTC

C006B-00 Stability System Active Too Long

ET21250100

17

29

31

18

16

4

19

8

2

1

2

1

1

2

1

2

FRONT LEFT
WHEEL SPEED
SENSOR

FRONT RIGHT
WHEEL SPEED
SENSOR

REAR LEFT
WHEEL SPEED
SENSOR

REAR RIGHT
WHEEL SPEED
SENSOR

R

Br

GY

WY

GR

GW

VB

V

GR

GW

VB

V

9

20

2

1

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

2

1

2

1

ABS
CONTROL
MODULE

13

12 11 10 9 8 7 6 5 4 3 2

24 23 22 21 20 19 18 17 16 15 14

37 36 35 34 33 32 31 30 29 28 27 26

1

38

25

B

E-085

E-085

W

E-029

B-054

E-029

B

B-009

B

B-029

B-009

B-029

B

E-036

B

E-060

1

2

1

2

E-036

E-060
