Chery Tiggo 5 (T21). Manual - part 236
18–
133
18
23.Remove the transmission and engine connecting bolts
(arrow).
(Tightening torque: 75 - 85 N·m)
24.Remove the engine rear mounting.
25.Use a proper tool (1) to separate the transmission (2)
from the engine.
26.Take out the transmission plate.
27.Remove the transmission.
Installation
Installation is in the reverse order of removal.
RT21180740
2
1
RT21180750
RT21180760
CAUTION
Turn crankshaft clockwise from the front of engine.
When installing torque converter, temporarily tighten the bolts and then tighten them to the specified
torque.
Keep transmission parts clean, and prevent foreign matter from entering into the transmission.
Add automatic transmission fluid.
After installation, inspect the gear shift lever for gear shift positions. Adjust the gear shift cable as
necessary.
