Lubrication Areas during Engine Assembly
All engine lubricants should be 5W-40 (for winter)/10W-40 (for summer) SM grade or higher.
Lubrication Area
Note
Piston Pin
SM10W-40
Piston Ring
SM10W-40
Piston
SM10W-40
Cylinder Bore
SM10W-40
Main Bearing Shell and Crankshaft Main Journal
SM10W-40
Crankshaft Thrust Washer (Oil Groove Side)
SM10W-40
Connecting Rod Bearing Cap Bolt Head and Thread
Part
SM10W-40
Connecting Rod Bearing Shell and Crankshaft
Connecting Rod Journal
SM10W-40
Main Bearing Cap Bolt Head
SM10W-40
Crankshaft Front Oil Seal Lip and Crankshaft Oil
Seal Journal
SM10W-40
Crankshaft Rear Oil Seal Lip and Crankshaft Oil Seal
Journal
SM10W-40
Valve Guide Hole
SM10W-40
Valve Stem
SM10W-40
Camshaft Cam and Journal
SM10W-40
Hydraulic Lifter
SM10W-40
Hydraulic Lifter Hole, Valve Rocker Arm
SM10W-40
Valve Small End, Valve Rocker Arm Head
SM10W-40
Valve Retainer Hole (Cylinder Head Assembly)
SM10W-40
Valve Guide or Guide Bottom Hole (Cylinder Head)
SM10W-40
Camshaft Oil Seal Lip and Camshaft Journal
SM10W-40
Oil Filter Gasket Surface
SM10W-40
