Chery Tiggo T11 LHD. Manual - part 139





Fuel

Fuel tank capacity:

Gasoline engine: 57 liters

Use the following fuel level only, and
use   the   high   quality   fuel   containing
the   cleaning   agents   and   other
additive agents. Using the lower level
fuel can damage the engine.

If   you   can’t   buy   the   high   quality
gasoline   containing   additives
temporarily, or when the engine has
such   defaults   as   poor   start,
inconsistent   idle   or   poor   power   and
etc,   a   proper   amount   of   additives
shall   be   added   when   refueling.   The
fuel additives play a role in preventing
the   engine   from   corroding   and

scaling, and cleaning the fuel system,
and   also   can   prevent   the   throttle
valve casing from freezing within the
temperature range of 0 to 15

℃.

The Chery Authorized Service Station
has   the   fuel   additives   in   stock
certified by this company. The staff of
the service station is accomplished in
its   application   method   and   the
method   to   process   the   scale   of
engine,   and  provide   you   with   warm
service.

Please   don’t   use   the
additives   or   engine

treatment   agents   without   the
authorization   of   this   company.
These   additives   aren’t   only
unnecessary   to   use,   but   also

may   damage   the   engine   under
some   conditions.   This   kind   of
damage   is  NOT  covered  in  this
warranty.

You   may   hear   the   fizz   sound   when
you open the fuel filler cap. And this
is normal and can be overlooked.

93# above unleaded gasoline
(its octane value is above 93)

It is no harmful to use the unleaded
gasoline with higher octane value, but
it   seems   there   is   no   greater
advantage.

The   car  equipped  with   the   catalytic
converter   must   use   the   unleaded
gasoline only.

To   avoid   the   occurrence   of   filling

improper   fuel,   the

necked   refill

opening

 design is applied for the fuel

tank   to   enable   the   compressor   gun
for unleaded gasoline only to stretch
into the opening to fill fuel.

If   you   fill   the   leaded
gasoline   into   the   fuel

tank   by   accident,   please   don’t
start up the engine (even if filling
a little of leaded gasoline only).
The   lead  contained  in   the   fuel
may   make   the   oxygen   sensor
and catalytic converter damaged
permanently. It is recommended
to   contact   the   nearest   Chery
Authorized   Service   Station
immediately.

Engine oil

Replace engine oil

It   is   recommended   by   the   Chery
Company to use the full synthetic oil
10W-30 engine oil. The design for our
automobile engine specifies to apply
this kind of engine oil. To achieve the
optimal   performance,   please   take
care to use the engine oil as required.
The viscous SAE 5W-40 engine oil is
also available.

Add engine oil

If   you   can’t   find   the   engine   oil
conforming   to   these   specifications,
you must use the viscous SAE 5W-
30,   SAE   10W-   40   or   SAE   5W-40
engine   oil   according   to   the   outside
temperature. Using these engine oils

Outside temperature

Recommended oil

may   generate   the   extended   start
time,   poor   engine   performance   and
poor   fuel  economical  efficiency,  and
increases the exhaust emission.

Any Chery Authorized Service Station
will keep the related records on date
to renew the oil, and will also use the
recommended engine oil.

If you require the detailed comments
or   information,   each   Chery
Authorized   Service   Station   will
pleasantly help you.

Please   don’t   use   the
engine   oil   that   doesn’t

conform to the specification and
requirement   above   because
these improper engine oils may
damage   the   engine,   which   this

kind of damage is NOT covered
in this warranty.

The   added   engine   oil
level shall not be higher

than   the   MAX   mark   on   the   dip
stick.

Please  don’t   use  the
additional   additives   or

engine   treatment   agents
because   these   additives   aren’t
only   unnecessary   to   use,   but
also   may   damage   the   engine
under   some   conditions.   This
kind of damage is NOT covered
in this warranty.

Automobile oil/fluid

Please replace the oil/fluid according
to   the   time   interval   listed   in   the
Maintenance Manual.

Transmission oil

Manual transmission

Check   the   oil   level  regularly  during
the normal inspection period.

Power   assisted   steering
oil

Use   the   hydraulic   oil   conforming   to
the Chery Company’s specification.

Brake fluid and clutch oil

The Dot 4 brake fluid is available, and
is   added   to   the   MAX   mark   as

required.

The brake fluid without paraffin wax is
available only.

In the case of heavy load
(with  trailer, a long time

driving in the mountain area, for
example),   it   shall   be   performed
to   simultaneously   replace   the
brake gasket and the brake fluid.
It must be ensured that the brake
system   is  absolutely  clean
during   adding   the   brake   fluid,
and   it   may   make   the   braking
performance   if   any   foreign
polluted   substances  enter   into
the braking system.

Coolant

The   coolant   with   compounding   ratio
of   50%   SOFT   WATER   and   50%
ETHYLENE GLYCOL is available.

Window   glass-cleaning
fluid

Fill   the   stock   tank   with   the   Chery’s
window   glass-cleaning   concentrated
solution   and   water   (1:20).   If   the
outside   temperature   is   lower,   the
winter window glass-cleaning fluid is
applied.

For correct  concentration refer to the
description on the container.

Do   not   throw   away   the
empty/waste   oil   container

and   cleaner   as   domestic   waste.

Please   use   local   authorized   waste
disposal facilities.

Capacity (L)

Engine oil

With cleaner

4.3

Power

 assisted

system steering

MAX mark

Cooling system

7.5

Wind



glass-

cleaning system

MAX mark

Fuel tank

57

Brake   fluid/clutch
oil stock tank

MAX mark

WOC (Weight of Car)

Please follow the vehicle
