Chery Tiggo T11 LHD. Manual - part 70
Service Manual for Chery·Tiggo(T11) Engine Section
Belt gear of balance axle
Screw bolt of camshaft belt gear
Belt gear of balance axle
4.6
9.0
4.6
Fuel System
Throttle
EGR valve
Injector and distribution pipe
Fuel oil return pipe
Fuel pressure regulator
1.9
2.2
1.2
0.9
0.9
Intake Manifold
Screw bolt of engine flying rings
Engine coolant temperature sensor
Connecting bolt of outflow pipe
Manifold bolt
Coolant temperature sensor
Manifold bracket
1.9
3.0
2.0
2.0
1.1
1.4
Exhaust Manifold
Screw bolt of emission manifold cover
Screw bolt of inflow duct joint
Exhaust manifold nut ( M8)
Exhaust manifold nut ( M10)
Screw bolt of coolant bypass duct joint
Screw bolt of coolant duct component
Thermostat
housing bolt
Water pump screw bolt
1.4
2.4
3.0
5.0
2.4
1.3
2.4
1.4
Rocker and Camshaft
Rocker cover screw bolt
Screw bolt of rocker and camshaft assembly
Trust bearing cover bolt
0.4
3.2
1.9
Cylinder Cover and Valve
Cylinder cover bolt
2.0
＋90°＋90°
Front cover & Engine oil pump
Drain plug
Oil pan
Screw bolt and nut of oil strainer
Oil pressure switch
Pressure relief plug
Screw bolt of oil cleaner bracket
Front cover bolt
Plug
Flange bolt
4.5
0.7
1.9
1.0
4.5
1.9
2.4
2.4
3.7
6
