Emergency situation

-Insert jack crank handle into jack and
turn jack handle clockwise to raise
vehicle until the rising head of jack is
seated in recess tightly and wheel is off
the ground(about 3cm).Do not raise
vehicle too high and recheck jack
position against slipping when jack
contacts vehicle and vehicle begins to
rise .

-Turn wheel attaching bolt anticlockwise

to remove bolts , then remove wheel..
-Install spare wheel in place and tighten
wheel bolts clockwise by hand.
-Rotate jack anticlockwise to lower
vehicle to the ground. Tighten wheel
bolts according to requirement on "
diagonal " order(1 - 2 - 3 - 4).

-Install wheel cover If improper wheel
bolts are used or bolts are not tightened
properly, wheel may get loose or break
off causing vehicle out of control.
-Apply proper wheel bolts-Ensure that
wheel bolts are positioned rightly and
tightened firmly.
-Do not apply engine oil or lubricant on
wheel bolts.

Notice

Vehicle may be in instable state when
using jack, even causing
accident.,Therefore:1

Position jack in

right jacking points.2

Position jack

perpendicular to the ground during
installation.3

Do not get under jacked

vehicle and do not start vehicle on jack.4,
Before jacking, have all passengers out of
vehicle to safe area.5

Jack is designed

only for wheel replacement.6

Do not

jack vehicle on slope or smooth
surside.7

Position jack at the side nearer

to the wheel to be replaced and hold the
wheel diagonal to the wheel to be
replaced.8

Before jacking, ensure that

hand braking is applied and transmission
is in" 1"gear or "R" gear if necessary.9
Do not replace tire where is near the
place with heavy traffic.Special Notice:If
you are not sure about tire replacement,
contact the nearest CHERY AUTO
authorized service station for help.

Emergency situation

Start engine by jumper
wire

The battery from other vehicle may be
used to start engine if vehicle battery is
not charged enough to start vehicle. Any
improper operation may result in battery
explosion , personal injury or property
damage and cause vehicle electric system
failure to a certain extent.:
-Do not have battery near open fire or
spark
-Do not have battery electrolyte contact
eye, skin, fabric or lacquer finish.
Electrolyte contains sulphuric acid
which may cause injury by direct contact.
-Wear protective glasses when operating
near battery in order to decrease the
danger of being harmed.
-Ensure that the battery from vehicle for

starting has the same voltage(12V) with
the original battery
-Do not disconnect battery which is not
well charged.
-Shut electrical load which is not
necessary.
-Do not bend over battery during starting
by jumper.
-Do not have two leads for starting
shorted.
-Apply hand brake and put transmission
control lever in neutral gear. Connect one
end of the first jumper to the positive pole
(there is "+" mark on battery box or
terminal) on the following method
-Connect the other end of the jumper to
the positive pole ("+" mark)of the battery
which is not well charged
-Connect one end of the second jumper to
the negative pole of the battery which

is from other vehicle( marked with " - ").
-Connect the other end of the second
jumper to the engine body or engine
supporting screw of another vehicle. Do
not connect jumper to the negative
terminal of the battery which is not well
charged. Connection points should be
away from the battery which is not well
charged as far as possible. Position
jumpers properly avoid contacting the
moving parts of engine compartment.
-The vehicle which offers battery source
may run during jumper start. The vehicle
with battery not well charged should be
started within 1 minute
Emergency situation
And continuous starting time is not
allowed to be more than 12 seconds.
Connection should be disconnected once
engine is started.

Notice

When engine is started by jumpers. all
electrical equipments should be shut off

in case other systems or parts be damaged.
do not start vehicle by pushing or
pulling.,Thus,three way catalytic
converter and other electronic parts

may be damaged.

Emergency situation

Vehicle Towing

If vehicle needs to be towed, contact the
nearest CHERY AUTO authorized
service station. Proper lifting and towing
procedure should be taken to prevent
vehicle from damaging. When vehicle is
towed by raising wheels, the following
steps should be taken:

Turn on the hazard warning lamps on

both vehicles.

Put ignition switch in " I " position.

Put gear control lever in neutral.

-Release hand brake.
-Vehicle should be towed with driving
wheels(front wheels) away from the
ground.

Notice

if vehicle is towed from the rearward
with front wheels on ground,
transmission may be damaged badly.
.So vehicle should be towed by raising
front wheels. vehicle could also be towed

by lifting rope transportation equipment
assisted with flat plate or wheel lift
device.

emergency towing

During emergency towing, towing
auxiliary equipment is likely to be used.
There is a special tow hook attached on
the front and rear bumper of vehicle.
When vehicle is towed with tow hook
and hauling cable:

-Open tow hook cover
-Fasten cable to tow hook.
-Turn on the hazard warning lamps on
both vehicles.
-Put gear shift lever in neutral and release
hand brake.
-Put ignition switch in " II " position to
unlock steering column , which enable
stop lamp,horn and windshield wiper to
operate.
-Only driver in leading vehicle may
control turning and braking.

-Shut

the

window

towed

vehicle

and

have for control lever in internal

circulation mode to prevent leading

Emergency situation

vehicle exhaust from getting into towed
vehicle.
-Start slowly to avoid bumping.

Notice

When vehicle is towed by hauling cable ,
towed vehicle may be out oftowed if
wheel, transmission , turning or braking
system is damaged. Meanwhile, the
following points should be taken:1

not remove ignition key. For steering lock
may be locked causing steering system
incapable to turn.2

Ensure that two

ends of hauling cable is attached on
hauling hook firmly. Push and pull
hauling cable to check for tightening.3
When other vehicle is towed , apply rear
hauling hook.

Self-aid

when in floppy road When vehicle gets
into the pit of floppy ground andcan not
be removed out, wiggle vehicle to get out

of pit and put gear shifter repeatedly from
X gear to R gear ,then from R gear to X
gear. Meanwhile,depress accelerator
pedal lightly. Do not idle engine to avoid
overheating or other parts damaging. Ask
for help if vehicle is still jammed after
several operations.

Notice

Vehicle may be trapped when driving on
snowfield, sand or muddy land. Do not
run wheels at high speed because racing a
engine in this condition may damage
driven elements.

control. So vehicle should not be
