Instruments and control devices

46

Notice

For windshield should not be wiped when
there is no water in washer tank, so front
sight will be affected. Therefore,1.Stop
vehicle to add washing liquid if it is
necessary to clean windshield during
running.2.Check washing liquid level
before a travel. In cold weather,
windshield may freeze, which will disturb
driver's sight. Windshield should be
heated before it is applied. Do not apply
wiper if there is no water in washer tank.
Do not apply washer more than
overheating may damage 10 seconds in
case washer motor. In cold weather,
washing liquid may expand, which may
damage washing fluid tank and result in a
washer failure. Hence, it is sufficient to

fill   washing tank with washing fluid to
3

4 of its capacity. Turning control lever

in the reverse direction of steering wheel
may operate luggage compartment cover
wiper and washer.

First position (Rest position)=Wiper
operative
Second position (Arm turning
position)=Wiper and washer operative
simultaneously When control lever is
moved to first position, wiper will work;
when control lever is moved to second
position, washing liquid will be injected
to rear window.

Notice

With no water, rear window wiper's
operation may scrape glass, which will
result in a premature deterioration of
wiper blades and disturb driver's front
visual field. Therefore, do not apply rear
window wiper when there is no water
available.

Adjustment Switch of
Headinglight Beam

Turn on headlight low beam and adjust
headlight beam scope for making a clear
view of front road.
0=Off
1=Front and rear foglight power switch
2=Headlight switch
Night light control switch is design to
regulate the intensity of instrument
cluster lighting.

Instruments and control devices

47

Hazard warning
flashlight switch

When hazard warning flashlight switch
on dashboard is pressed, hazard-warning
flashlight will be turned on and all turn
signal light will light up simultaneously.
After once more a press, all lights go out
at the same time. Hazard warning
flashlight may be operated no matter
whether ignition switch is turned on.
Apply hazard warning flashlight to warn
other drivers and try to avoid stopping on

driveway when a emergency parking or
traffic handicapping is avoidless.

Rear window defroster
switch

With ignition switch in"

"position, rear

window may be defogged or defrosted by
pressing rear window defroster switch.
When rear windshield defroster is
operative, the indicator light on rear
window defroster switch will come on.
Rear windshield defroster may be turned
off by pressing switch once more.

Notice

For rear windshield defrosting heating
element is attached to the inner surside of
rear windshield, defrosting function will
be out of work if heating element is
damaged.,Hereby, sharp tools or cleaning
solution with corrosive ingredient
contained is not allowed to used for
cleaning the inner surside of rear window.
Defroster will consume a great deal of
power, which may cause battery
discharging. Hereby, defroster is not
suggested to apply before engine is
started. Rear windshield defroster should
be shut once cleaning is finished. In snow
weather, the snow on rear windshield
should be cleaned first ,then rear window
defroster switch may be turned on.

Instruments and control devices

48

Digital clock

After ignition switch is turned on ,digital
clock will indicate time. There is a button
on digital clock which is designed to
adjust time when necessary:Press button
and hold on for 4 seconds, the hour
number on clock will blink frequently.
Accordingly, every button press will
increase an hour of the time on digital
clock .After hour time adjustment is
finished, wait for 5 seconds and the
minute number on digital clock will blink
automatically,Accordingly, every button
press will increase one minute of the time
display on digital clock .When time
display does not blink after time
adjustment is finished and wait for
several seconds, all time adjustment is
finished.

Notice

Clock should be readjusted if battery is
ever disconnected or fuse is replaced.

Cigarette lighter

With ignition switch in "I” or"
"position,cigarette lighter will work
once button   is pressed.
Cigarette lighter will be ejected
automatically when it gets hot.

Notice

Cigarette lighter heating pipe will get hot
during functioning, which may cause a
burning. Do not touch cigarette lighter
heating pipe. children are forbidden to
toy with cigarette lighter .Do not press
cigarette lighter when it gets extremely
hot. Do not mistake cigarette lighter
socket as a receptacle, which may cause
damage or   electrical failure.

Front ashtray

Pulling it backwards may open front
ashtray. Push it back in place after usage.
If ashtray needs to be emptied, open
ashtray completely and depress metal
boat, then pull out ashtray.

Instruments and control devices

49

Horn button

Horn will blow if steering wheel (without
airbag) center or the left/right side of
steering wheel (with driver's airbag) is
pressed. Horn may blow whatever
position ignition switch is. Try to avoid
using horn.

Cup holder

Cup holder is located on front console
and designed to hold cup.

Notice

With vehicle running, the liquid in cup
may spill out. So do not use cup holder
while driving.

Interior light

There is three positions for interior light.

"on" position:Interior light will remain on
despite door is open or not.
“DOOR Position”:(Between "ON"
position and "OFF" position "):Interior
light will illuminate when vehicle door is
opened.
“OFF' Position:Interior light will not
illuminate even if door is open.

Glove box

Glove box may be opened by
pulling its handle.Glove bow can
be closed by pushing glove case
smoothly.
