Start and Operation

If the first brake oil path failed, the car
can still brake with the second oil path.
When this happens, you need to step on
the brake pedal with more strength. The
brake distance will be prolonged. Please
go to the Chery Service Station to check
the brake system before continuing with
your drive.
If the brake pedal is lower than before,
you need to adjust the rear drum brake. If
this happens, please test your car forward
and backing and test the brake in all
directions to find out the reason.
If the pedal does not get back or the
distance is too long, please contact with
Chery Service Station, because this
probably is a signal for the fault in brake.

Notice

The brake might invalidate if it is

overheated. So 1 Use engine brake under
low gear when driving down a
declivity2

Do not use the brake

continuously.
If the components of the brake are humid,
the brake will not function for a while. So
take a look at behind for any other cars
and step slightly on the brake pedal to
check whether the function has lost. Then
keep the distance with other cars for
enough space, and step slightly on the
brake pedal until it get back to work.
When crossing water (which is deep
enough to wet the components) or after a
washing, repeat the above process to
avoid any accident. The brake friction
piece and the brake cushion might be
worn. So do not lay your feet on the
brake pedal during driving.

ABS

ABS is a kind of advanced electric brake

system which can prevent the car from
sliding during a brake.
ABS is to prevent the wheel from locking
in an emergency brake or on a smooth
road, and to keep the swerving and
stability of the car.
This system use sensor to detect the
differences among each wheel speed and
begin to function when the wheel is going
to lock. The system detected the wheel
speed before locking and control relative
brake with electric signal.
When opening the ignition switch, the
ABS alarm light glitters for automatic
check and shut down in 4-5 seconds. If
the alarm light does not shut down or
light up during driving, it indicates there
is trouble with the ABS. The car can still
brake regularly without ABS. Please
contact with Chery Service Station if this
happens.

Start and Operation

Brake with ABS

Do not fear the vibration of the brake
pedal. Step down the brake pedal and
maintain until starting the ABS no matter
how the road status is.
ABS adjusts the brake pressure of each
wheel for best performance and does not
loose direction stability or steering
control at the same time.
When the ABS is operating, there might
be slight vibration with some noise. This
kind of vibration and noise display the
ABS is working normally.
In an emergency, step down brake pedal
and clutch pedal at the same time, and the
ABS immediately takes effect so as you
can fully control the steering.
We suggest you to familiarize with these
performances to avoid unnecessary
danger.

ABS Self-check

After starting the engine, ABS begins to
self-check.
ABS self-checks is to check for system
fault. You can hear a slight mechanical
noise which is normal.

Notice

Brake distance will differ according to
the road and running condition, so 1.
keep a safe distance with the front car. 2.
drive slowly on humid or smooth roads.
ABS can not prevent any accident caused
by careless or false operations, so 1. drive
carefully.2. decelerate when steering.3.
Step on the brake pedal forcibly and
maintain. When the ABS alarm light
enlightened, it shows there is fault with
ABS, so 1. Stop and contact with Chery
Service Station.2. check by the experts
before continue to drive.

Manual Brake

The manual brake takes effect on the rear
wheel. Pull it up and the rear wheel
automatically locked.
Manual brake joystick is between the
front seats.
Pull up the manual brake joystick to lock
the rear wheel. Pull slightly in the
direction (1) and press the button (2) on
the top of the joystick and lay it down
along (3), then the manual brake is
released.
Loose the manual brake completely
before driving.
If you want to adjust the manual brake,
please refer to the Chery Service Station.

Start and Operation

Stopping the car
l

Step down the brake pedal and
strain the manual brake.

When stopping on a horizontal road,
set the joystick to neutral gear
position. When stopping on a brae
(driving down), set the gear joystick
to back up. When stopping on the
brae (driving up), set the joystick to
1 speed position.

Close all the windows and
clearstory.

Turn the ignition key to “B”, and
pull off the key.

Lock all the doors and trunks.

Ensure the car has stopped
completely.

Notice

The exhaust components are so hot that
may cause fire. Do not stop on flammable
things, such as grass or straw. The car
might move when stopping, so1. pull up
the manual brake. 2. choose the hard road
to stop. 3. Do not back to the straight
direction when stopping on the
mountain.4. If you did not loose the
manual brake, it will do harm to the rear
brake. Loose the manual brake
completely before driving. The
flammable things will self-ignite if it
touches the hot exhaust components on
the bottom of the car. The manual brake
will be frozen if crossing the water
(which is deep enough to make the
components humid) or after washing. If it
froze, you should1. Pull up the manual
brake, and set the gear joystick to 1-speed
or back up; 2. lock the rear wheel to
ensure the car can not move; 3. Loose the
manual brake.

Suggestion on
Economized peration

The economy of fuel depends on your
operation. The way you drive, the place
and the time you drive will influence the
distance that 1 L fuel can drive.
For best fuel economy:
l

Start smoothly and accelerate
slowly.

Adjust the engine properly.

Do not leave the engine running in
idle.

Use air conditioner if it is really
needed (if there is the equipment).

Decelerate when driving on an
accidented road.

Keep the air pressure in the tyre
with standard for the best fuel
economy and prolong the life of the
tyre.

Keep certain distance with other

cars to avoid emergency brake so as

to depress the wear and tear of the

Start and Operation

brake patch and improve the fuel

economy(because there is no need

for additional fuel to accelerate).

Do not load unnecessary goods to

add the weight.

Do not leave your feet on the pedal

which will cause unnecessary worn

or even damage the brake and

increase the consume of fuel.

Keep the condition when the car

left the factory.

Notice the exhaust gas of the engine

(carbon monoxide)

Do not inhale the exhaust gas of the

engine which is harmful, or you

will examinate or even die with

excessive gas.

Whenever you suspect that there is

exhaust gas entering the car, go to the

Chery Service Station immediately for a

check. If you have to drive under this

condition, please open all the windows

completely.

To prevent the gas from entering the car,

please check the exhaust system and body

regularly.
l

Lift the car and check when

replacing the oil.

Notice the change of the sound of

exhaust system.

Do not let the exhaust system,

chassis or the tail be damaged or

corroded.

Notice at the same time:

Do not start the engine in a narrow

place such as garage or other closed

places.

When the engine maintain running

for a long time in an open

circumstance, you should set the

conditioner to outer circulate mode

and let the fresh air into the car, and

set the blower to high speed

position.

Do not stay in a car with engine

running idle for a long time, neither

leave the children in it.

Avoid the tail door open during a

driving because the exhaust gas

might get into the car. If the tail

door has to be opened, please close

all the windows. Set the conditioner

to outer circulate mode and let the

fresh air into the car, and set the

blower to high speed position.

Driving in danger:

When driving on watery, snowy, icy,

muddy, sandy or similar kind of

dangerous roads, you should follow these

advices:

Start and Operation
l

Drive carefully for the brake

distance will be prolonged.

Avoid brake or steering.

Step slightly on the brake pedal
