Chery S11 / Chery QQ. Manual - part 277

SQR7080&7110 Maintenance & Service Manual

11

For more details, see Quality
Warranty Items, and can also consult

from local Chery Authorized Service
Station

Scheduled Maintenance Rules

Complete Regulate Maintenance at Chery Authorized Service Station

Mileage

Km

Item

5000

15000

30000

Light, warning flasher, horn: check performance

Wiper and washing system: check performance, add washer fluid if necessary

Check clutch free pedal travel, adjust it if necessary

Cooling system: check antifreeze level, replace if necessary

Oil: Replace

Oil filter: Replace

Engine: check leakages (oil, antifreeze, fuel, A/C system)

Engine: adjust valve clearance (only applied on SQR 7160 sedan)

Battery: check electrolyte solution level, refill distilled water if necessary

SQR7080&7110 Maintenance & Service Manual

12

Mileage

Km

Item

5000

15000

30000

Timing belt: check belt tension and wear, adjust or replace if necessary.

Engine hood hinge and lock: lubricate

Door hinge and door stopper: lubricate

Spark plug: check and replace if necessary

Air filter: clean shell, clean filter element and replace it if necessary.

Ignition timing: check

Fuel filter: replace

Exhaust system: check if leak and damage

Wedge belt: check tension, adjust or replace as necessary

Driver: check if leak or damage

Constant velocity joint dust boot: check if damaged

Steering tie rod joint: check clearance and if dust boot damaged

Steering universal joint assembly boot: check if misplaced or damaged

SQR7080&7110 Maintenance & Service Manual

13

Mileage

Km

Item

5000

15000

30000

Power steering system: check if power steering oil level, steering gear & rack clearance

improper

Brake system: visually check if leak or damage and brake fluid level

Hand brake: check the travel, adjust if necessary

Brake lining: check its thickness

Under-body protective cover: check if damaged

Seat belt: check if damaged

Toe-in value and camber angle: measure, adjust if necessary

Ball pin: check the clearance

Engine oil sump bolt: check if loose, tighten if necessary

Control arm rubber boot: check if damaged

Braking hose: check if aged or damaged

Braking pipe: check if damaged, eroded or leaky connection

Fuel system connections: check if aged, damaged, abnormal loosening or rubbing

SQR7080&7110 Maintenance & Service Manual

14

Mileage

Km

Item

5000

15000

30000

Tire (including spare tire): check tires veins depth, adjust tire pressure, check wheel bolt

tightening torque.

Tires exchange

Chassis and body connecting bolts: check if loose, tighten if necessary

Wheel: check if loose

Rear wheel hub bearing: check clearance and lubricating condition

CO content at idle: measure and adjust if necessary

Road test: check if all mechanism operates normally.

Note:

For manual transmission, replace gear oil in transmission case every year or 30,000 km. Replace brake fluid every 2 years or

50,000 km.
