Chery    QQ    Maintenance Manual                        Transmission System



fork, install the bearing. Spread lubricant on the splined    hub , install the    spacer NO.2
and  seal .

Fix the release fork cover.

  6, Fix the release shaft on the release fork, aim at the riveted mark and tighten the

bolt .

7,Used 2 bolt fix up lable bracket, disassembly clutch    cable bracket.

Pack the clutch separation arm



Lubricate the  release fork
assembly and the input shaft.
Screw the torque tightly.



N.m


Kg-m


1b-ft



Release shaft      bolt



10-16 10-1.6 7.5-11.5

Lable  bracket bolt



18-28 1.8-2.8

13.5-20.0














Section 5 Recommended Torque.



Screw the torque tightly


N.m Kg-m

1b-ft


1,Switch Lock nut


10-15 1.0-1.5

7.5-10.5

2,Clutch  cable bolt


4-7 0.4-0.7

3.0-5.0

3,Flywheel bolt


57-65 5.7-6.5

41.5-47.0

4,The clutch cover stud
bolt


18-28 1.8-2.8

13.5-20.0

5,Release shaft bolt

10-16

1.0-1.6

7.5-11.5

-32-



Chery    QQ    Maintenance Manual                        Transmission System




6,Cable bracket bolt


18-28 1.8-2.8

13.5-20.0




Section 6 Necessary Maintenance    Materials



Material


The SUZUKI
product of the
recommendation

Use the part


The SUZUKI             high
class lubricates the fat A
(99000-25010)

Pull the lable carries
connect pin.
Release fork spacer and

seal.

Release bearing and
Release shaft.



The lithium lubricates the
fat


The SUZUKI             high
class lubricates the fat I
(99000-25210)

Input shaft Splined hub
and forepart

Waterproof sealant


The SUZUKI             seals
completely the 366 Es
(99000-31090)

Clutch cable and front
clap board.








-33-



Chery    QQ    Maintenance Manual                        Transmission System





Flywheel holding

tool

Bearing Replacer

tool

Input shaft

bearing Replacer

Clutch guide tool

Puller slide

hammer

Bearing replacer

tool

Spacer replacer

tool

Hub tool

Bearing replacer

tool
























-34-

Chapter 2 Transaxle



Chery    QQ    Maintenance Manual                        Transmission System



Section 1    DABS10-4 Transaxle


I,A gearbox technique brief introduction of section 1



Main Functions
And Technical Data

DABS10-4,DABS10-8 Transaxle


A type

Machine gear type

Gearshift

Compare soon

The gear number
compare

1



st

3.416

41/12

2 nd

1.894

36/19

3 rd

1.28

32/25

4 th

0.914

32/35

5 th

0.757

25/33

Reverse

3.818

42/35/11

The lord reduce

4.389

79/18

Speedometer

0.944

17/18

Max input torque

72 N ·m

Contour size

409×392×342.7（mm）

Transaxle

5°

Lubricant

18#  hyperbolic gear oil（Q/SH006·1·27-89）


II, Driven  special
This transaxle, consist of three groups of synchronizer,input shaft and    output shaft,

is to realize the ahead shaft and reverse.

All the gear are gear, slip idler gear is for reverse .
The synchronizer is fixed on the output shaft , joggled with output shaft,the    1st gear

and the 2nd gear; the synchronizer is fixed on the input shaft, joggled with the 3 rd,4th
gear .

The 5th synchronizer on the input shaft is joggled with the 5th gear fixed on the

input shaft, thereby dive the transmission shaft and the wheels.
