Chery                        SQR7160 series sedan ABS system－fault diagnostic and repairing













nostic Chart













Beginning

Ignition off, connect scan tool.

Turn ignition to ON position

Enter 03 (electronic brake) at ADDRESS

NO

Is there communication?

YES



go to FAULT W/O CODEDIAGNOSTIC
CHART
go to FAULT CHECK CHART,
WITHOUT CODES

Enter 02 (error inquiry) at ADDRESS

Intermittent fault (display with /SP)

Continuous Fault

Clearing fault code

Recording fault code

Go to INTERMITTENT FAULT

DIAGNOSTIC PROCEDURE,

repair problem.

Go to FAULT W/CODE DIAGNOSTIC CHART,

repair problem.

Clearing fault code

Turn ignition off, disconnect scan tool.

Not Normal

Vehicle Drive Test

Normal

END

1. Faut Diagnostic Flow Chart

1

Chery                              SQR7160 series sedan ABS system－fault diagnostic and repairing



Chery                        SQR7160 series sedan ABS system－fault diagnostic and repairing











2. Fault Diagnostic Precaution

      ABS is an electronic hydraulic controlled system and below condition is normal when ABS is under normal

operating condition.



Condition Explanation

System self-check sound

After engine on, bumping similar sound may occurs from

engine compartment sometime. It is the sound of ABS

system self-check and is normal.

Sound when ABS operating

1. Sound of motor running in ABS hydraulic unit.

2. Sound of brake pedal viabrating.

3. When ABS operating, creaking sound from suspension

dashing or friction sound between tire and ground。



Note: Tire may also creak when ABS is under normal

operating.

ABS operating, but a long brake distance.

When running on snowy or sandy road, a ABS installed

vehicle braking distance is longer than a vehicle without

ABS sometime. Special care shall be used when driving

on such road surface.



2











3. Scan Tool, Operating Method and Function Introduction

3.1 Operating Method

    *  Ignition off, connect scan tool to diagnostic connector, then turn ignition on.

    *  Enter 03, then press Q key，ABS will be in operation condition.

    *  Enter the function code.

    *  Enter 06, then press Q key，exiting。

*    After power off, remove scan tool.



3.2 Function Introduction

*  Function 01—condition information display

*  Function 02—fault inquiry

*  Function 03—hydraulic controlled unit diagnostic

*  Function 04—filling fluid and bleeding

    *  Function 05—clearing fault codes memory

    *  Function 06—end，exit.

    *  Function 07—controller programme

*  Function 08—measured data display (such as wheel speed signal etc.)



3.3 Key

        *    Key    C          —    Cancel, change input data and current menu

        *    Key    Q        —   Confirm entering

        *    Key    →        —      Next

        *    Key    HELP      — Help Information

3
