深 圳 市 元 征 科 技 股 份 有 限 公 司

  LAUNCH TECH CO., LTD.



                                                                    深圳市元征软件开发有限公司      LAUNCH SOFTWARE DEVELOPMENT CO.,LTD.

地址:518112 广东省深圳市龙岗区坂雪岗工业区五和大道北元征工业园

ADD:

 LAUNCH INDUSTRIAL PARK,NORTH OF WUHE ROAD,BANXUEGABF,LONGGANG DISTRICT, SHENZHEN,P.R,CHINA.



电话

TEL:86-755-84528427  传真 FAX:86-755-84528454









保留一切解释权，处置权，包括复印及传达至第三方。








编写：黄惠生    2008-9-11      15:01    第 247 页      总 274 页

"P0035","Turbocharger/Supercharger Bypass Valve Control Circuit High"
"P0234","Turbocharger/Supercharger Overboost Condition"
"P0236","Turbocharger/Supercharger Boost Sensor “A” Circuit Range/Performance "
"P0237","Turbocharger/Supercharger Boost Sensor “A” Circuit Low "
"P0238","Turbocharger/Supercharger Boost Sensor “A” Circuit High"
"P0243","Turbocharger/Supercharger Wastegate Solenoid “A” "
"P0245","Turbocharger/Supercharger Wastegate Solenoid “A” Low "
"P0246","Turbocharger/Supercharger Wastegate Solenoid “A” High"
"P0299","Turbocharger/Supercharger Underboost "
"P1297","Manufacturer controlled computer and auxiliary outputs "
"P2261","Turbocharger/Supercharger Bypass Valve – Mechanical "
"U0001","High Speed CAN defectiv"
"U0101","Lost Communication with TCM"
"U0104","Lost Communication With Cruise Control Module"
"U0121","Lost Communication With Anti-Lock Brake System (ABS) Control Module"
"U0155","Lost communication with Instrument Panel Cluster control module"
"U0415","Invalid data received from ABS control module"


11.1.2  玛瑞利 472 电控系统

;0x4719
"P0105","Ppressure sensor"
"P0110","Air temperature sensor"
"P0115","Water temperature sensor"
"P0120","Throttle position sensor"
"P0130","Lambda 1"
"P0134","Sonda lambda 1 pre-cat nessuna attività rilevata "
"P0135","Lambda 1 Heater "
"P0136","Lambda 2"
"P0140","Sonda lambda 2 post-cat nessuna attività rilevata"
"P0141","Lambda 2 Heater "
"P0170","Diagnosi ko2 fuel System"
"P1170","Diagnosi gain fuel System "
"P0201","Injector Cylinder 1 "
"P0202","Injector Cylinder 2 "
"P0203","Injector Cylinder 3 "
"P0204","Injector Cylinder 4 "

PDF 文件使用 "pdfFactory Pro" 试用版本创建

ÿ















www.fineprint.com.cn

深 圳 市 元 征 科 技 股 份 有 限 公 司

  LAUNCH TECH CO., LTD.



                                                                    深圳市元征软件开发有限公司      LAUNCH SOFTWARE DEVELOPMENT CO.,LTD.

地址:518112 广东省深圳市龙岗区坂雪岗工业区五和大道北元征工业园

ADD:

 LAUNCH INDUSTRIAL PARK,NORTH OF WUHE ROAD,BANXUEGABF,LONGGANG DISTRICT, SHENZHEN,P.R,CHINA.



电话

TEL:86-755-84528427  传真 FAX:86-755-84528454









保留一切解释权，处置权，包括复印及传达至第三方。








编写：黄惠生    2008-9-11      15:01    第 248 页      总 274 页

"P0230","Fuel pump "
"P0300","misfire random recognized "
"P0301","misfire cil. 1"
"P0302","misfire cil. 2"
"P0303","misfire cil. 3"
"P0304","misfire cil. 4"
"P0325","Knock Sensor-In running"
"P0335","Engine speed sensor "
"P0340","HW Phase Sensor "
"P0351","Coil 1"
"P0352","Coil 2"
"P0420","efficiency catalyst "
"P0443","Canister"
"P0460","Fuel level"
"P0480","Low speed fan "
"P0481","High speed fan"
"P0500","Vehicle speed signal"
"P0505","Stepper motor "
"P0560","Battery voltage "
"P0601","E2PROM checksum fault "
"P0604","Ram fault "
"P0605","Rom fault "
"P0606","Microprocessor fault"
"P0654","Tachometer"
"P1300","Learning Phonic wheel "
"P1325","Knock Sensor-At Key on "
"P1430","Air conditioner Frost Sensor"
"P1531","A/C compressor relais "
"U1600","Immobilizer "

11.1.3  联合电子发动机系统 EOBD 模块

;0x4661
"P0016","Crankshaft Position-Camshaft Position Correlation Bank 1 Sensor A"
"P0030","O2 Sensor Heater Contr. Circ.(Bank1(1)Sensor 1)"
"P0031","O2 Sensor Heater Contr. Circ.(Bank1(1)Sensor 1) Low"
"P0032","O2 Sensor Heater Contr. Circ.(Bank1(1)Sensor 1) High "
"P0036","O2 Sensor Heater Contr. Circ.(Bank1(1)Sensor 2)"

PDF 文件使用 "pdfFactory Pro" 试用版本创建

ÿ















www.fineprint.com.cn

深 圳 市 元 征 科 技 股 份 有 限 公 司

  LAUNCH TECH CO., LTD.



                                                                    深圳市元征软件开发有限公司      LAUNCH SOFTWARE DEVELOPMENT CO.,LTD.

地址:518112 广东省深圳市龙岗区坂雪岗工业区五和大道北元征工业园

ADD:

 LAUNCH INDUSTRIAL PARK,NORTH OF WUHE ROAD,BANXUEGABF,LONGGANG DISTRICT, SHENZHEN,P.R,CHINA.



电话

TEL:86-755-84528427  传真 FAX:86-755-84528454









保留一切解释权，处置权，包括复印及传达至第三方。








编写：黄惠生    2008-9-11      15:01    第 249 页      总 274 页

"P0037","O2 Sensor Heater Contr. Circ.(Bank1(1)Sensor 2) Low"
"P0038","O2 Sensor Heater Contr. Circ.(Bank1(1)Sensor 2) High "
"P0053","O2 Sensor Heater Resistance(Bank1(1)Sensor 1)"
"P0054","O2 Sensor Heater Resistance(Bank1(1)Sensor 2)"
"P0101","Mass or Volume Air Flow Circ. Range/Performance"
"P0102","Mass or Volume Air Flow Circ. Low Input"
"P0103","Mass or Volume Air Flow Circ. High Input "
"P0105","Manifolt Absolut Pressure/Barometic Pressure Circuit "
"P0106","Manifold Abs.Pressure or Bar.Pressure Range/Performance"
"P0107","Manifold Abs.Pressure or Bar.Pressure Low Input"
"P0108","Manifold Abs.Pressure or Bar.Pressure High Input "
"P0112","Intake Air Temp.Circ. Low Input"
"P0113","Intake Air Temp.Circ. High Input "
"P0116","Engine Coolant Temp.Circ. Range/Performance"
"P0117","Engine Coolant Temp.Circ. Low Input"
"P0118","Engine Coolant Temp.Circ. High Input "
"P0121","Throttle/Pedal Pos.Sensor A Circ. Range/Performance"
"P0122","Throttle/Pedal Pos.Sensor A Circ. Low Input"
"P0123","Throttle/Pedal Pos.Sensor A Circ. High Input "
"P0130","O2 Sensor Circ.,Bank1-Sensor1 Malfunction"
"P0131","O2 Sensor Circ.,Bank1-Sensor1 Low Voltage"
"P0132","O2 Sensor Circ.,Bank1-Sensor1 High Voltage "
"P0133","O2 Sensor Circ.,Bank1-Sensor1 Slow Response"
"P0134","O2 Sensor Circ.,Bank1-Sensor1 No Activity Detected "
"P0136","O2 Sensor Circ.,Bank1-Sensor2 Malfunction"
"P0137","O2 Sensor Circ.,Bank1-Sensor2 Low Voltage"
"P0138","O2 Sensor Circ.,Bank1-Sensor2 High Voltage "
"P0140","O2 Sensor Circ.,Bank1-Sensor2 No Activity Detected "
"P0170","Fuel Trim,Bank1 Malfunction"
"P0171","Fuel Trim,Bank1 System too Lean"
"P0172","Fuel Trim,Bank1 System too Rich"
"P0201","Cylinder 1- Injector Circuit "
"P0202","Cylinder 2- Injector Circuit "
"P0203","Cylinder 3- Injector Circuit "
"P0204","Cylinder 4- Injector Circuit "
"P0219","Engine Overspeed Condition "
"P0221","Throttle/Pedal Position Sensor/Switch B Range/Performance"
"P0222","Throttle/Pedal Position Sensor/Switch B Low Input"

PDF 文件使用 "pdfFactory Pro" 试用版本创建

ÿ















www.fineprint.com.cn

深 圳 市 元 征 科 技 股 份 有 限 公 司

  LAUNCH TECH CO., LTD.



                                                                    深圳市元征软件开发有限公司      LAUNCH SOFTWARE DEVELOPMENT CO.,LTD.

地址:518112 广东省深圳市龙岗区坂雪岗工业区五和大道北元征工业园

ADD:

 LAUNCH INDUSTRIAL PARK,NORTH OF WUHE ROAD,BANXUEGABF,LONGGANG DISTRICT, SHENZHEN,P.R,CHINA.



电话

TEL:86-755-84528427  传真 FAX:86-755-84528454









保留一切解释权，处置权，包括复印及传达至第三方。








编写：黄惠生    2008-9-11      15:01    第 250 页      总 274 页

"P0223","Throttle/Pedal Position Sensor/Switch B High Input "
"P0261","Cylinder 1- Injector Circuit Low "
"P0262","Cylinder 1- Injector Circuit High"
"P0264","Cylinder 2- Injector Circuit Low "
"P0265","Cylinder 2- Injector Circuit High"
"P0267","Cylinder 3- Injector Circuit Low "
"P0268","Cylinder 3- Injector Circuit High"
"P0270","Cylinder 4- Injector Circuit Low "
"P0271","Cylinder 4- Injector Circuit High"
"P0300","Random/Multiple Cylinder Misfire Detected"
"P0301","Cyl.1 Misfire Detected "
"P0302","Cyl.2 Misfire Detected "
"P0303","Cyl.3 Misfire Detected "
"P0304","Cyl.4 Misfire Detected "
"P0318","Rough Road Sensor ""A"" Signal Circuit "
"P0321","Ign./Distributor Eng.Speed Inp.Circ. Range/Performance "
"P0322","Ign./Distributor Eng.Speed Inp.Circ. No Signal "
"P0324","Knock Control System Error "
"P0327","Knock Sensor 1 Circ. Low Input "
"P0328","Knock Sensor 1 Circ. High Input"
"P0340","Camshaft Position Sensor Circuit "
"P0341","Camshaft Pos.Sensor Circ. Range/Performance"
"P0342","Camshaft Pos.Sensor Circ. Low Input"
"P0343","Camshaft Pos.Sensor Circ. High Input "
"P0420","Catalyst System,Bank1 Efficiency Below Threshold "
"P0444","Evaporativ Emiss.System Purge Control Valve Circ. Open "
"P0458","Evaporative Emission System Purge Control Valve Circuit Low"
"P0459","Evaporative Emission System Purge Control Valve Circuit High "
"P0480","Cooling Fan 1 Control Circuit"
"P0481","Cooling Fan 2 Control Circuit"
"P0501","Vehicle Speed Sensor Range/Performance "
"P0506","Idle Control System RPM Lower than Expected"
"P0507","Idle Control System RPM Higher than Expected "
"P0508","Idle Air Control System Circuit Low"
"P0509","Idle Air Control System Circuit High "
"P0511","Idle Air Control Circuit "
"P0532",""A/C Refrigerant Pressure Sensor Circuit low Input"
"P0533",""A/C Refrigerant Pressure Sensor  Circuit high Input"

PDF 文件使用 "pdfFactory Pro" 试用版本创建

ÿ















www.fineprint.com.cn
