"U0001","High Speed CAN defectiv"
"U0101","Lost Communication with TCM"
"U0104","Lost Communication With Cruise Control Module"
"U0121","Lost Communication With Anti-Lock Brake System (ABS) Control Module"
"U0155","Lost communication with Instrument Panel Cluster control module"
"U0415","Invalid data received from ABS control module"
5.1.4 联合电子 2.0 电控系统
;0x4661
"P0016","Crankshaft Position-Camshaft Position Correlation Bank 1 Sensor A"
"P0030","O2 Sensor Heater Contr. Circ.(Bank1(1)Sensor 1)"
"P0031","O2 Sensor Heater Contr. Circ.(Bank1(1)Sensor 1) Low"
"P0032","O2 Sensor Heater Contr. Circ.(Bank1(1)Sensor 1) High "
"P0036","O2 Sensor Heater Contr. Circ.(Bank1(1)Sensor 2)"
"P0037","O2 Sensor Heater Contr. Circ.(Bank1(1)Sensor 2) Low"
"P0038","O2 Sensor Heater Contr. Circ.(Bank1(1)Sensor 2) High "
"P0053","O2 Sensor Heater Resistance(Bank1(1)Sensor 1)"
"P0054","O2 Sensor Heater Resistance(Bank1(1)Sensor 2)"
"P0101","Mass or Volume Air Flow Circ. Range/Performance"
"P0102","Mass or Volume Air Flow Circ. Low Input"
"P0103","Mass or Volume Air Flow Circ. High Input "
"P0105","Manifolt Absolut Pressure/Barometic Pressure Circuit "
"P0106","Manifold Abs.Pressure or Bar.Pressure Range/Performance"
"P0107","Manifold Abs.Pressure or Bar.Pressure Low Input"
"P0108","Manifold Abs.Pressure or Bar.Pressure High Input "
"P0112","Intake Air Temp.Circ. Low Input"
"P0113","Intake Air Temp.Circ. High Input "
"P0116","Engine Coolant Temp.Circ. Range/Performance"
"P0117","Engine Coolant Temp.Circ. Low Input"
"P0118","Engine Coolant Temp.Circ. High Input "
"P0121","Throttle/Pedal Pos.Sensor A Circ. Range/Performance"
"P0122","Throttle/Pedal Pos.Sensor A Circ. Low Input"
"P0123","Throttle/Pedal Pos.Sensor A Circ. High Input "
"P0130","O2 Sensor Circ.,Bank1-Sensor1 Malfunction"
"P0131","O2 Sensor Circ.,Bank1-Sensor1 Low Voltage"
"P0132","O2 Sensor Circ.,Bank1-Sensor1 High Voltage "
"P0133","O2 Sensor Circ.,Bank1-Sensor1 Slow Response"
