MAIN BEARINGS (Cont’d) Installation Check the bearing spread as listed [A]. Limit – 2.93 inch (74,5 mm) Check to see if the bearing has enough tension, so that Check the crankshaft journals before installing the main Make sure to position the bearing halves in their correct Lubricate the new bearings. Install them by putting the Install the other bearing half in the bearing cap. Lubricate Lubricate the bolts, install them finger tight only. Install the center main bearing and thrust washers [D]. The thrust washer must be installed so that their oil Repeat the procedure until all the main bearings and caps A B–08241 C B–08254 No Oil Groove and Hole (Lower Side) With Oil Hole and Groove (Upper Side) Fit Correctly D B–08255 853, 853H Loader –7–65– Service Manual B B–08242 |
