BYD M6. Service Manual - part 7
BYD M6 AUTO Owner’s Manual
CAUTION
Left Bottom Small Glove
Glove Compartment
Box
Make sure the carpet mat is
fastened properly. If the carpet mat
slides ahead or interferes with pedal
operations, it may cause an
accident in driving.
Press the button to open the top right
The left bottom glove box is located
glove box, and press the cover
under the left air outlet.
downward to close it.
Pull down the handle on the top of the
Pull out the handle in the square hole
glove box to open it.
to open the bottom right glove box,
and push the glove box upward to
Push it upward to close it.
close it.
Other Equipments 1-92
BYD M6 AUTO Owner’s Manual
Card Box
Rear Quarter Armrest Seat
Auxiliary Fascia Console
Slide cover
Cupholder
Rear quarter armrest seat
You can keep cards in the card box.
You can place a cup or ashtray in the
You can place a cup or bottle in the
cupholder.
cupholder.
Insert a card in the direction shown in
the figure, the clamp in the card box
Do not place a tall article in the
will firmly hold down the card.
cupholder; otherwise it may topple
down when operating the hand brake.
To take out the card, just pull it
outward.
You can keep small articles in the
slide cover of the auxiliary fascia
console.
Other Equipments 1-93
BYD M6 AUTO Owner’s Manual
NOTICE
Rear Door Panel
Switch button
Partition panel
Slide cover
Auxiliary fascia
y When the vehicle is moving, lock
console glove box
the slide cover to prevent
damage to it.
y Do not place a tall article in the
glove box; otherwise it may
topple down when operating the
hand brake.
Front Door Panel
The glove box under the auxiliary
fascia console has large capacity.
There is a cupholder in the rear door
To open the console glove box, press
panel.
the switch button to unlock it, and
then slide the cover backward. You
can take out the partition panel to get
larger capacity. To close the console
glove box, slide the cover forward and
let the switch button engage firmly.
There is a cupholder and document
holder in the front door panel.
Other Equipments 1-94
BYD M6 AUTO Owner’s Manual
Cigarette Lighter
Power Sockets
NOTICE
y
To prevent the fuse from blowing
out, the total power consumption
Push
should not exceed 12V/120W.
in
y
To prevent the battery from
overdischarge, do not use any
electric appliance when the
engine is not running.
y
Put the cover back in place
when the power socket is not in
use. To prevent electric failure or
short circuit, do not insert
The Start button must be pressed
Power socket provides
power
to
anything other than the proper
down before using the cigarette
electric appliances.
power plug into the power
lighter.
When the Start button is at ACC or
socket, and prevent liquids from
To use the cigarette lighter, just push
ON, pull up the cover to use the
entering it.
it in; when it is ready for use, it will pop
power socket.
up. Do not hold down the cigarette
lighter to prevent overheating.
Other Equipments 1-95
BYD M6 AUTO Owner’s Manual
Parking Assist System (if
The parking assist system uses a
Sensors
sensor to detects obstacles and thus
equipped)
assist the driver in parking the vehicle,
CAUTION
prompting the distance between the
vehicle and obstacles through the
Please strictly follow the safety
multifunction display, touch screen or
instructions below; otherwise it
buzzer.
could cause an accident.
Parking assist system does not
y Do not use the sensor when the
relieve you of the responsibility of
vehicle is moving at high speed.
paying attention. You should always
1. Front corner sensor
y Do not place any thing in the
observe the area around the vehicle.
operating range of the sensor.
2. Rear corner sensor
3. Rear center sensor
NOTICE
y Do not clean the sensor with
water or steam; otherwise it may
cause trouble to the sensor.
Other Equipments 1-96
BYD M6 AUTO Owner’s Manual
Parking Assist Switch
Display
y Touch Screen Display
(if
equipped)
The parking assist switch is located at
When an obstacle is detected, an icon
the left bottom side of the steering
will be displayed on the multifunction
wheel.
screen and touch screen, depending
on the form of the obstacle and its
distance to the vehicle.
y Multifunction Display
1. Front corner sensors working
2. Rear corner sensors working
3. Rear center sensors working
The parking assist system works if
When an obstacle is detected, the
you press the switch when the Start
1. Front corner sensors working
image will be displayed automatically.
button is at ON, and the shift lever is
at P or any gear other than Neutral.
2. Rear corner sensors working
If there is no front or reversing vision
3. Rear center sensors working
signal, the image will be displayed on
Turn on: press the switch.
the full screen.
The
indicator on the multifunction
screen comes on and the buzzer
sounds once.
Turn off: press the switch again.
Other Equipments 1-97
BYD M6 AUTO Owner’s Manual
Distance Display and Buzzer
How Corner Sensors Work
Parking assist system
Warning
Approximate
When an obstacle is detected, its
Warning
Distance
Display
Tone
direction
and the approximate
(mm)
distance to the vehicle are displayed
Observe around the vehicle to
on the screen, and the buzzer will
600-500
ensure safety
Fast
sound.
If there is front or reversing signal, the
How Rear Center Sensors Work
image will be displayed on the top
right corner of the screen.
Long
Approximate
500 or less
Warning
beep
Distance
Display
Tone
(mm)
1200-800
Slow
800-500
Fast
Long
500 or less
beep
Other Equipments 1-98
BYD M6 AUTO Owner’s Manual
Active Sensors
Sensor Detection
CAUTION
When the vehicle moves forward, the
In the following cases, this system
y
This system is intended as an
front corner sensors are working;
may not work properly:
aid to assist you to park your
when the vehicle is in reversing, all
y
When dirt, water or fog build up on
vehicle and is not a substitute for
sensors are working.
the sensor;
your personal judgment. You
must operate the vehicle based
y
When the sensor is frozen in ice or
on your observations.
snow;
y
Do not put any object on or near
y
When the sensor is covered by
the operating range of the
any object;
sensors. Otherwise it may cause
y
When the vehicle is apparently
failure of this system, or even an
tilting or overloaded;
accident.
y
When driving on bumpy, sloped or
y
In certain situations, the system
graveled roads or on grass;
Some 600mm
Some 600mm
will not function properly and
y
When the sensor is repainted;
when the vehicle approaches
y
When a device such as a horn
certain objects, the system will
from another vehicle, motorcycle
not detect those objects.
engine, or an air brake sound from
Therefore, do not rely solely on
a heavy-duty vehicle, generates
Some 500mm
Some 1200mm
this system and always observe
ultrasonic waves near your
the area around the vehicle.
The detection range of each sensor is
vehicle;
shown in the figure. The detection
y
When the vehicle is close to
range is limited as shown in the figure
another vehicle equipped with the
above. Check the area around and
parking assist system;
drive slowly.
Other Equipments 1-99
BYD M6 AUTO Owner’s Manual
y When a towing hitch is mounted
y Objects with sharp edges or
Parking Vision System (if
on your vehicle;
corners;
equipped)
y When the bumper or sensor
y Objects low in height, such as a
The parking vision system provides
experience intensive striking;
curbstone;
real-time view around the vehicle to
y When the vehicle is approaching a
y High objects with the top
help you in parking.
high or winding road curb;
stretching out toward the vehicle;
This system works in two modes:
y When the vehicle is in very hot or
y Objects beneath the bumper;
reversing vision and front right vision.
cold weather;
y Objects close to the vehicle;
y When a non-genuine suspension
y A person near the vehicle
CAUTION
is installed;
(depending on the type of clothes
y
This system is designed to work
worn)
In addition, the distance of certain
together with the parking assist
obstacles may not be detected
When the buzzer keeps sounding or
system and interior/exterior
properly due to their particular
when the icons appear on the
rearview mirrors. Don’t rely
shapes.
multifunction display or touch screen
entirely on this system. In
if no obstacle is close to the vehicle,
The sensors may not work if an
narrow space, it is good have
have your vehicle checked at a BYD
obstacle is in an odd shape or made
someone guide you in parking.
service station.
of material that does not reflect
y
You must observe around the
ultrasonic waves. The system may
vehicle rather than only look at
not detect the following:
the display. Your estimate of the
distance to the obstacle based
y Thin objects such as a wire or
on the display may vary
rope;
significantly
with the real
y Cotton, snow or other objects that
distance. Relying entirely on the
absorb ultrasonic waves;
display may cause collision with
Other Equipments 1-100
BYD M6 AUTO Owner’s Manual
a walker, obstacle or another
cloth. If the taint, such as oil or
light will cause unstable image
vehicle. You must observe the
rubber stains, is hard to remove,
on the display, and in turn affect
area around the vehicle even if
please wash it with water and
your observation and parking, or
you have a parking vision
mild detergent, and then wipe it
even cause an accident.
system.
clean with a soft cloth.
y
Don’t use this system if the rear
y
Don’t get any organic solvent,
NOTICE
door is not closed completely.
wax, detergent or window film on
y
After collision with another
the camera. In case of any stain
In the following cases, the image
vehicle or any obstacle, there
of these matters, remove it
may not be distinguishable even
may be change in the camera
immediately.
though the system is working
location and orientation. Contact
y
You must look around the
normally:
a BYD service station to check
vehicle rather than rely on the
In the dark
the camera location and
display alone. When the vehicle
y
If the temperature around the
orientation.
is moving, the image may be
camera is very hot or cold;
blurred, distorted or dark,
y
Don’t disassemble or modify the
y
If the humidity is very high, or if
especially on a cold day. Be sure
waterproof installation camera.
water drops are stuck on the
to observe the area around the
Otherwise it may not work
lens;
vehicle and use the rearview
properly.
mirrors when parking.
y
If snow or mud is stuck on the
y
If
the ambient temperature
lens;
changes quickly, this system
y
Don't use the parking vision
system when you turn on the
y
If the lens is scratched or dirty;
may not work properly.
turn signal lights or emergency
y
If the lens is directed at a strong
y
If water, snow or mud gets on
flashers. Don’t use the parking
light source.
the camera, wash it with water
vision system when there is
and wipe it clean with a soft
lights blinking nearby. A blinking
Other Equipments 1-101
BYD M6 AUTO Owner’s Manual
A strong point light source will be
Objects under the bumper
press the OFF button on the steering
displayed as a light spot on the
wheel.
screen, making the surrounding
The front right camera is installed on
objects indistinguishable.
the right exterior rearview mirror.
Reversing Vision
The camera has a limit view angle.
When the Start button is at ON, set
The objects that is straight in front of
the shift lever to R position to enable
Front Right Vision
the vehicle or to the rear right of the
the reversing vision mode.
vehicle cannot be displayed in the
The reversing camera installed on the
front right vision.
rear door has a limit view angle. The
See the figures below:
objects near both ends of or under the
Objects straight in front of the vehicle
bumper cannot be displayed in the
reversing vision.
ON/Switch
See the figure below:
Off
Objects near both ends of the bumper
Press the Vision ON/Switch button on
the steering wheel to enable the front
Objects to the rear right of the vehicle
right vision.
The floor lights will come on to provide
lighting around the vehicle if the
outside is dark.
To turn off the parking vision system,
Other Equipments 1-102
BYD M6 AUTO Owner’s Manual
Parking Operation
Display on touch screen
The front right camera is installed on
the exterior right rearview mirror.
Turn on the parking vision system
when parking your vehicle.
You can use the front right vision
mode if reversing is not required.
Move the vehicle to the parking space
while observing the area around the
vehicle and looking at the parking
vision display
While reversing, you can switch
The lines are reversing safety lines.
between the reversing vision and front
Display on touch screen
Red: 0-0.5m
right vision by operating the Vision
Yellow: 0.5-1.5m
button, so that you can see the blind
Green: 1.5-2.5m
corners.
The reversing camera is installed on
CAUTION
the rear door.
y The reversing safety lines serve
as reference lines only for a
no-load vehicle.
The range displayed in the vision may
vary with the vehicle orientation and
road conditions.
Other Equipments 1-103
BYD M6 AUTO Owner’s Manual
Don’t rely alone on this system since
km/h).
Changing Cruising speed
it is intended as an aid to assist you to
3. Press the Decelerate/Set Up
You can increase the preset cruising
park your vehicle.
button (-/Set Up) on the steering
speed by any of the following
wheel. The Cruise indicator on the
Always observe the area around the
operations:
instrument panel will come on,
vehicle and make correct decisions
indicating that this function is
y
Press and hold Speed Up/Reset
while parking. Make sure there is
activated.
button
(+/Reset) to increase the
sufficient space for vehicle maneuver
speed; Release the button when
before parking.
The cruise control cannot maintain
you reach your desired speed.
the speed on uphill/downhill roads. If
Cruise Control (if
y
Press down the accelerator pedal.
you are going too fast on a downhill
equipped)
road, apply the brake to slow down
Press the Decelerate/Set Up (-/Set
the vehicle. However the cruise
Up) button when you reach your
The right combination switch controls
control will be cancelled. To restore to
desired speed.
the cruise.
the cruising speed, press the Speed
y
To slightly increase the cruising
When the power in at ON, press the
Up/Reset button
(+/Reset). The
speed, short press the Speed
cruise
control
master button
Cruise indicator on the instrument
Up/Reset button
(+/Reset) in a
(ON/OFF), the Cruise indicator on the
panel will come on.
repeat pattern. The cruising speed
instrument panel will come on.
increases by 1.6 km/h with each
On an uphill road, the automatic
Activating Cruise Control
1.
button press.
transmission may downshift to
When the power in at ON, press
You can decrease the preset cruising
maintain the cruising speed.
the cruise control master button
speed by any of the following
(ON/OFF), the Cruise indicator on
operations:
the instrument panel will come on.
y Press the Decelerate/Set Up (-/Set
2. Speed up the vehicle to the
Up) button to slow down the
desired cruising speed (above 40
Other Equipments 1-104
BYD M6 AUTO Owner’s Manual
vehicle. Release the button when
Canceling Cruise Control
comes on and the vehicle will
you reach your desired speed.
accelerate until it reaches the
You can cancel the cruise control by
y
Slightly press down on the brake
previous cruising speed.
any of the following operations:
pedal, and the Cruise indicator on
If you press the cruise control master
the instrument panel will go out.
y Press down the brake pedal.
button (ON/OFF), the system will be
When you reach your desired
y Press the Cancel Cruise Control
turned off with the saved cruising
speed,
short
press
the
button
(Cancel) on the steering
speed cleared.
Decelerate/Set Up
(-/Set Up)
wheel.
button. The vehicle will maintain
Vehicle Telephone System
y Press the cruise control master
the desired speed.
button (ON/OFF) on the steering
(if equipped)
y
To slightly reduce the cruising
wheel.
For details on the vehicle telephone
speed,
short
press
the
When you press the Cancel button or
system, refer to the user manuals of
Decelerate/Set Up
(-/Set Up)
slightly step down on the brake pedal,
the vehicle multimedia
system
and
button in a repeat pattern. The
the Cruise indicator on the instrument
mobile phone.
cruising speed reduces by
1.6
panel goes out and the vehicle will
km/h with each button press.
slow down. At this time, you can
y
When cruise control is activated,
operate the accelerator pedal as
you can still step down the
usual.
accelerator pedal for overtaking.
The system has saved the previous
When overtaking is finished,
cruising speed. To resume the
release the accelerator pedal and
previous cruising speed, speed up the
the vehicle will return to the preset
vehicle to more than
40 km/h and
cruising speed.
then short press the Speed Up/Reset
y
Resting your foot on the brake
button (+/Reset). The Cruise indicator
pedal will cancel the cruise control.
Other Equipments 1-105
BYD M6 AUTO Owner’s Manual
2 Chapter 2 Sound and A/C System
2.1 Sound System
AM/FM Radio
2-4
Electronic Clock
2-6
Operation of USB / AUX Interface (if equipped)
2-7
Play a CD
2-7
Steering Wheel Control of Sound System (if equipped)
2-10
Sound System 2-1
