BMW 323ci Convertible (2000 year). Instruction - part 8
98nAutomatic climate control
Rear window defroster
Activated charcoal filter
When the rear window defroster
An activated charcoal filter has been in-
is activated, the indicator lamp
stalled in your BMW to filter the outside
comes on. The rear window defroster
air and to catch any incoming dust and
switches off automatically. Refer to
pollen. It provides additional protection
page 79.
by filtering gaseous pollutants from the
outside air. Your BMW center can re-
place the combined filter as a standard
part of your scheduled maintenance.
A substantial reduction in air flow indi-
cates that the filter needs to be replaced
early.
Draft-free ventilation
You can adjust the blower controls for
the upper body area to select the opti-
mum airflow rates and directions for
your personal comfort:
Use rotary dials 1 to open and close the
air outlets through an infinitely-variable
range. You can adjust the direction of
the airflow with rotary dial 2.
Set the air outlets so that the air flows
past you and is not directed straight at
you.
Rotary dial 3 allows you to mix the the
air from the outlets for your upper body
by warming or cooling the air as de-
sired.
Seat heating*
Glove compartment
99n
To prevent injury in the event of
a crash, close the glove compart-
ment immediately after use.<
Rechargeable flashlight
The flashlight is located on the left-hand
side of the glove compartment.
It features integral overload protection
so it can be left in its holder continuously.
Be sure that the flashlight is
switched off when it is inserted
The seat cushion and backrest can be
To open
into its holder. Failure to do so could
heated when the ignition key is in posi-
Pull the handle. The lamp comes on.
lead to overcharging and damage.<
tion 2.
You can call up different heating modes
Closing
by repeatedly pressing the button.
Fold the cover up.
When the three indicator lamps are
illuminated, the highest heating mode
To lock
is activated. One lamp indicates the
Lock with one of the master keys.
lowest heating mode. The temperature
A master key can also be used for
is regulated with a thermostat in
unlocking.
each mode.
You can also switch the higher heating
If you turn over only your door
modes off directly:
and ignition keys for valet parking
Press the button and hold it slightly
(refer to page 32), for example, access
longer.
to the glove compartment and the lug-
gage compartment is not possible.<
100nBMW Universal Transmitter *
The concept
To Canadian residents:
Checking for the conversion code
During programming, your hand-
The BMW Universal Transmitter re-
To determine whether the original
held transmitter may automatically stop
places up to three hand-held transmit-
hand-held transmitter has a conver-
transmitting after two seconds. This
ters for different devices such as ga-
sion-code system, you may either read
may not be long enough to program the
rage-door openers, alarm systems, or
the instructions for the original hand-
BMW Universal Transmitter. If you are
door-locking systems. The BMW Uni-
held transmitter or program a channel
programming from one of these hand-
versal Transmitter recognizes and
key as described on the next page (left-
held transmitters, the Universal Trans-
"learns" the transmitted signal of each
hand column under "Programming").
mitter's light may begin to flash in a
of the original hand-held transmitters.
Then press and hold the programmed
series of double-blinks. If this occurs,
The signal of an original hand-held
channel key of the BMW Universal
continue to hold the button of the Uni-
transmitter can be programmed on one
Transmitter. If the indicator lamp of
versal Transmitter while you reactivate
of the three channel keys. Following
the BMW Universal Transmitter flashes
your hand-held transmitter. You may
that, each of the devices can be actu-
for two seconds and then stays on
have to repeat this function several
ated with the appropriately pro-
steadily, the original hand-held trans-
times while programming.<
grammed channel key. The indicator
mitter is equipped with a conversion-
lamp flashes to confirm transmission
code system. Using the conversion-
Before programming, read the
of the signal.
code system, program the channel keys
"User information" section on
as described on the next page (right-
If the vehicle is sold, the memory of the
page 102.<
hand column under "Programming a
channel keys should be cleared as de-
hand-held transmitter using conversion
scribed on page 102.
Original hand-held transmitter
code").
If this symbol is present on the
During programming and before
packaging or in the instructions
If you have additional questions,
every remote actuation of a pro-
of the original hand-held trans-
please consult your BMW center
grammed device by the BMW Universal
mitter, it may be assumed that this
or call 1-800-355-3515.
Transmitter, check to be sure that there
hand-held transmitter is compatible
You can also visit this website:
are no persons, animals or objects
with the BMW Universal Transmitter.
www.bmwusa.com.<
within the actuation range of the device
in order to prevent possible injuries or
damage. Also, comply with the safety
precautions of the original hand-held
transmitter.<
BMW Universal Transmitter *
101n
Programming a hand-held
transmitter with conversion code
Read and comply with the safety
precautions on previous page.<
When programming the BMW Universal
Transmitter, consult the instructions for
the specific device. For using the BMW
Universal Transmitter with a conver-
sion-code system, note the following
supplemental programming instruc-
tions:
Programming
3
Hold the original hand-held transmit-
1 Channel keys
ter to the receiver embedded in the
A second person facilitates pro-
mirror, e. g. right near the buttons, no
2 Indicator lamp
gramming of the BMW Universal
further than 2 inches away (5 cm)
Transmitter.<
4
Press the transmission key of the orig-
Read and comply with the safety
inal hand-held transmitter (arrow 2)
precautions on the previous
1 Program the BMW Universal Trans-
and the desired channel key of the
page.<
mitter as described previously under
Integrated Universal Remote Control
"Programming"
(arrow 1) simultaneously. Release
1 Turn the ignition key to position 2
2 Press and hold the programming key
both keys as soon as the indicator
2 To initialize: press and hold both out-
on the receiver of the device for ap-
lamp flashes rapidly
side keys 1 until the indicator lamp 2
proximately two seconds until the
5
To program other original hand-held
flashes, and then release them. The
programming lamp on the device
transmitters, repeat steps 3 and 4.
three channel keys are cleared
comes on
The corresponding channel key is now
3 Press the desired channel key of the
programmed using the signal from the
BMW Universal Transmitter three
original hand-held transmitter.
times.
If you have additional questions,
please consult your BMW center.<
102nBMW Universal Transmitter*
Storage compartments
Clearing the channel keys
User information
Do not use this BMW Universal Trans-
Read and comply with the safety
mitter with any garage door opener that
precautions on page 100.<
lacks safety "stop" and "reverse" fea-
tures as required by federal safety stan-
The memory of individual channel keys
dards (this includes any garage door
cannot be deleted. However, the three
opener model manufactured before
channel keys can be cleared together
April 1, 1982).
as follows:
This device complies with Section 15 of
> Press and hold both outside keys of
the FCC Rules. Operation is subject to
the BMW Universal Transmitter until
the following two conditions: as defined
the indicator lamp flashes, and then
in the regulations, this device must not
release them.
emit harmful interference, and must be
Open the storage compartment in the
All of the channel keys are cleared.
shielded against interference from ex-
front center armrest: press the button
ternal sources to prevent unauthorized
(arrow) and lift upward.
or inadvertent activation.
You will find additional storage com-
partments in the doors and in the center
console above the ashtray. Storage nets
are located on the back of the front
seats.
Storage compartments Cellular phone*
Ashtray front
103n
Cup holder, coin box
Hands-free system
To open
A coin box and two cup holders are
In vehicles with a telephone prepara-
Press briefly in direction indicated by
provided in the center console.
tion* or a communications package*,
arrow.
the cover for the hands-free micro-
To extinguish a cigarette, tap off the
phone is located above the rearview
ash and gently press the tip into the
mirror on the driver side.
funnel.
For further information on the cellular
phone, refer to the separate Owner's
Manual.
104nAshtray front
Cigarette lighter
Ashtray rear
To empty
Press the lighter in. Remove the lighter
To open
Press the edge of the lid (arrow): you
as soon as it retracts.
Push the cover open.
can now pull the ashtray upward for
removal.
Hold or touch the hot cigarette
To empty
lighter by the knob only. Holding
Press on the edge of the raised cover
or touching it in other areas could
in the opening direction (arrow). You
result in burns.
can now pull the ashtray upward for
The cigarette lighter remains opera-
removal.
tional when the ignition key has been
removed. For this reason, children
should never be left in the vehicle
unattended.<
Cigarette lighter socket
This socket can be used for connecting
a flashlight, car vacuum cleaner, or other
appliances up to approx. 200 watts at
12 volts. Avoid damaging the socket due
to inserting plugs of different shapes or
sizes.
Ski bag*
105n
The ski bag allows the safe and clean
transport of up to three pairs of skis or
two snowboards.
The length of the ski bag and the addi-
tional space provided in the luggage
compartment make it possible to carry
skis with a length of up to 6.8 feet
(2.10 meters). Because of the tapered
shape of the bag, the ski bag can only
accommodate two pairs of skis that are
6.8 feet long (2.1 0 meters).
Loading
To re-attach the fill piece, guide
the tabs into the strip of molding
1 Release the safety belts from their
and snap the fill piece back into place.
holders
The safety belts can then be re-secured
2 Press down on the button (arrow) and
into their holders.<
remove the fill piece by pulling it for-
ward
3 Extend the ski bag between the front
seats. The zipper provides conve-
nient access to stored items. It may
be opened to allow the ski bag to dry
106nSki bag*
Cargo loading
To enlarge the luggage compart-
ment when the convertible top is
closed, refer to page 41.
We recommend that you always fold
the convertible top compartment panel
down as soon as you have unloaded
the luggage compartment. That way
you will always be sure of being able to
operate the convertible top at any time.
Reverse the process by flipping the
convertible top compartment panel up
before stowing any cargo in the lug-
gage compartment, which will (also)
Stowing cargo
4
Press the button in the luggage com-
prevent any damage to the convertible
partment (arrow)
If you are transporting a load in your
top compartment or the cargo.<
BMW:
5
Use the magnetic retainer to fasten
the cover panel to the back wall.
> Load heavy cargo as far forward as
possible - directly behind the back-
Securing the load
rests or the luggage compartment
partition - and as low as possible
Secure the skis or other objects in
> Cover sharp edges and corners.
the bag by tightening down the re-
taining strap at the buckle.<
Please ensure that the skis are clean
before loading them into the bag. Take
care to avoid damage from sharp
edges.
Cargo loading
107n
Always position and secure the
load correctly. If you do not, it can
endanger the passengers during brak-
ing or evasive maneuvers.
Do not exceed the permissible gross
vehicle weight and the permissible axle
loads (refer to page 184). If you do, safe
operation of the vehicle is no longer
ensured, and you are in violation of the
law.
Do not carry hard or heavy objects un-
secured in the passenger compartment.
If you do so, they may be projected
Securing the load
through the air during braking and eva-
> For small, light items, use the rubber-
sive maneuvers, thus endangering vehi-
lined non-skid side of the floor mat or
cle occupants.<
secure with a luggage compartment
net* or elastic straps (refer to
page 40)
> For large, heavy pieces, see your
BMW center for load-securing de-
vices*. Lashing eyes (arrow) are pro-
vided at the corners of the luggage
compartment for attaching these
load-securing devices
> Comply with the information enclosed
with the load-securing devices.
108nLuggage rack for the hardtop*
Make sure that the load is not too heavy,
and attempt to distribute it evenly.
Always load the heaviest pieces first (on
the bottom). Make sure nothing projects
into the luggage compartment lid's
opening and closing path.
Secure the roof luggage correctly and
securely to prevent it from shifting or
being lost during driving (danger to fol-
lowing traffic).
Drive smoothly and avoid sudden ac-
celeration or braking. Do not corner at
Mounting points
high speeds.
Access to the mounting points:
The roof load increases aerodynamic
To open the covers (arrow), please
resistance, resulting in increased fuel
use the tool included with the luggage
consumption and additional stresses on
rack system.
the vehicle body.
A special roof-rack system is available
for your BMW as an optional extra.
Please observe the precautions in-
cluded with the installation instructions.
Because roof racks raise the center of
gravity of the vehicle when loaded, they
exercise a major effect on its handling
and steering response.
You should therefore always remember
not to exceed the approved roof weight,
the approved gross vehicle weight or
the axle weights when loading the rack.
You will find the specifications under
"Technical Data" on page 184.
Index
Data
Technology Repairs
Car care
Controls
Overview
110n
111n
Special operating instructions:
Under the hood:
Overview
Break-in procedures
112
Hood 129
Driving notes
113
Engine compartment
130
Catalytic converter
113
Washer fluids
132
Antilock Brake System
Washer nozzles
132
(ABS)
114
Engine oil
133
Controls and features
Disc brakes
116
Coolant
135
Brake system
117
Brake fluid
136
Winter operation
118
Vehicle Identification
Power steering
120
Number 137
Operation, care
Cellular phone
120
Care and maintenance:
Radio reception
120
and maintenance
The BMW Maintenance
Hardtop
121
System 138
Wheels and tires:
Caring for your vehicle
139
Tire inflation pressure
123
Cleaning and caring for your
Owner service procedures
Tire condition
123
convertible top
144
Tire replacement
124
Airbags
146
Tire rotation
125
Vehicle storage
147
Wheel and tire
Laws and regulations:
Advanced technology
combinations
126
Technical modifications to the
Winter tires
127
vehicle
148
Snow chains 127
OBD interface socket
149
Approved wheel and tire
specifications
128
Technical data
Index
Car care
