Acura TLX (2019 year). Manual

Bluetooth® HandsFreeLink®

HFL Menus

342

Features

■

To make a call using the call history

Call history is stored by All

, Dialed,

Received, and Missed.
1. Press the PHONE button.
2. Rotate

to select Call History, then

press .

3. Move

select

All

, Dialed,

Received, and Missed.

4. Rotate

to select a number, then press

Dialing starts automatically.

1. Press the

button.

2. Move the left selector wheel right to select

Call History.

3. Roll the left selector wheel to select a

number.

4. Push the left selector wheel or the

button.

Dialing starts automatically.

*1: This function may not be available depending on a cellular phone.

To make a call using the call history

The call history displays the last 20 dialed, received, or
missed calls.
(Appears only when a phone is connected to HFL.)

These icons next to the number indicate the
following:

: Dialed calls.
: Received calls.
: Missed calls.

The call history displays the last 12 dialed, received, or
missed calls.

Steering switches

On Multi-Information Display

Steering switches

19 ACURA TLX-31TZ36400.book 342 ページ２０１８年２月１６日　金曜日　午後１２時２２分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

343

Bluetooth® HandsFreeLink®

HFL Menus

Features

■

To make a call using a speed dial entry

1. Press the PHONE button.
2. Rotate

select

Speed Dial, then press

3. Rotate

to select a number, then press

Dialing starts automatically.

1. Press the

button.

2. Move the left selector wheel left to select

Speed Dial.

3. Roll the left selector wheel to select a

number.

4. Push the left selector wheel or the

button.

Dialing starts automatically.

To make a call using a speed dial entry

Rotate

to select More Speed Dials to view

another paired phone’s speed dial list. You can make
a call from that list using the currently connected
phone.

When a voice tag is stored, press the

button to

call the number using the voice tag.

2 Speed Dial P. 336

Any voice-tagged speed dial entry, phonebook name
or number can be dialed by voice from any screen.
Press the

button and follow the prompts.

The speed dial displays the 20 speed dial entries.

Steering switches

On Multi-Information Display

Steering switches

19 ACURA TLX-31TZ36400.book 343 ページ２０１８年２月１６日　金曜日　午後１２時２２分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Bluetooth® HandsFreeLink®

HFL Menus

344

Features

When there is an incoming call, an audible
notification sounds (if activated) and the
Incoming Call screen appears.

Press the

button to answer the call.

Press the

button to decline or end the

call.

■

Receiving a Call

Receiving a Call

Call Waiting

Press the

button to put the current call on hold to

answer the incoming call.

Press the

button again to return to the current

call.
Ignore the incoming call if you do not want to answer
it.
Press the

button if you want to hang up the

current call.

Information Screen

On Demand Multi-Use Display

19 ACURA TLX-31TZ36400.book 344 ページ２０１８年２月１６日　金曜日　午後１２時２２分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

345

Bluetooth® HandsFreeLink®

HFL Menus

Features

The following options are available during a call.

Phone Call Active - Transfer to Mobile:
Transfer a call from HFL to your phone.

Mute: Mute your voice.
Transfer to Mobile: Transfer a call from HFL
to your phone.
Touch Tones: Send numbers during a call.
This is useful when you call a menu-driven
phone system.

The available options are shown on the On
Demand Multi-Use Display

Select the option.

The Mute icon is checked when Mute is
selected. Select Mute again to turn it off.

■

Options During a Call

Options During a Call

Touch Tones: Available on some phones.

Information Screen

On Demand Multi-Use Display

Mute Icon

Information Screen

On Demand Multi-Use Display

19 ACURA TLX-31TZ36400.book 345 ページ２０１８年２月１６日　金曜日　午後１２時２２分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Bluetooth® HandsFreeLink®

HFL Menus

346

Features

HFL can display newly received text and e-mail messages as well as 20 of the most
recently received messages on a linked cell phone. Each received message can be
read aloud and replied to using a fixed common phrase.

1. A pop-up appears and notifies you of a new

text or e-mail message.

2. Rotate

to select Read to listen to the

message, then press

The text or e-mail message is displayed.
The system automatically starts reading
out the message.

3. To discontinue the message read-out, press

■

Receiving a Text/E-mail Message

Receiving a Text/E-mail Message

The system does not display any received messages
while you are driving. You can only hear them read
aloud.

With some phones, you may be able to display up to
20 most recent text and e-mail messages.

State or local laws may limit your use of the HFL text/
e-mail message feature. Only use the text/e-mail
message feature when conditions allow you to do so
safely.

When you receive a text or e-mail message for the
first time since the phone is paired to HFL, you are
asked to turn the New Text/Email Alert setting to
On.

2 To turn on or off the text/e-mail message

notice P. 330

19 ACURA TLX-31TZ36400.book 346 ページ２０１８年２月１６日　金曜日　午後１２時２２分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

347

Bluetooth® HandsFreeLink®

HFL Menus

Features

If a paired phone has text message or mail accounts, you can select one of them to
be active and receive notifications.

1. Press the SETTINGS button.
2. Rotate

to select Bluetooth/Phone

Settings, then press

Repeat the procedure to select Select
Account.

3. Rotate

to select Text Messages or an

e-mail account you want, then press

■

Selecting a Mail Account

Selecting a Mail Account

You can also select a mail account from the folder list
screen or the message list screen.
Rotate

to select Select Account, then press

You can only receive notifications from one text
message or mail account at a time.

19 ACURA TLX-31TZ36400.book 347 ページ２０１８年２月１６日　金曜日　午後１２時２２分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Bluetooth® HandsFreeLink®

HFL Menus

348

Features

■

Displaying text messages

1. Press the PHONE button.
2. Rotate

to select Text/Email, then press

Select account if necessary.

3. Rotate

to select a message, then press

The text message is displayed. The
system automatically starts reading the
message aloud.

4. Rotate

to select View Full Message.

5. Press

to displays the full text of the

message.

■

Displaying Messages

Displaying Messages

The

icon appears next to an unread message.

If you delete a message on the phone, the message
will also be deleted from the system. If you send a
message from the system, the message goes to your
phone’s outbox.

To see the previous or next message, move

on the text message screen.

Message List

Text Message

19 ACURA TLX-31TZ36400.book 348 ページ２０１８年２月１６日　金曜日　午後１２時２２分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

349

Bluetooth® HandsFreeLink®

HFL Menus

Features

■

Displaying e-mail messages

1. Press the PHONE button.
2. Rotate

to select Text/Email, then press

3. Rotate

to select a folder, then press

4. Rotate

to select a message, then press

The e-mail is displayed. The system
automatically starts reading the message
aloud.

5. Rotate

to select View Full Message.

6. Press

to displays the full text of the

message.

Displaying e-mail messages

Received text and e-mail messages may appear in the
message list screen at the same time. In this case, text
messages are titled No Subject.

Folder List

Message List

E-mail
Message

19 ACURA TLX-31TZ36400.book 349 ページ２０１８年２月１６日　金曜日　午後１２時２２分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Bluetooth® HandsFreeLink®

HFL Menus

350

Features

■

Read or stop reading a message

1. Go to the text or e-mail message screen.

The system automatically starts reading
the message aloud.

2 Displaying Messages P. 348

2. Rotate

to select Stop Reading

Messages.

3. Press

to stop reading.

Press

again to start reading the message

from the beginning.

■

Reply to a message

1. Go to the text or e-mail message screen.

The system automatically starts reading
the message aloud.

2 Displaying Messages P. 348

2. Rotate

to select Reply, then press

3. Rotate

to select the reply message, then

press .

Message sent appears on the screen
when the reply message was successfully
sent.

Reply to a message

The available fixed reply messages are as follows:

•

Talk to you later, I’m driving.

•

I’m on my way.

•

I’m running late.

•

Yes

•

You cannot add, edit, or delete reply messages.

Only certain phones receive and send messages when
paired and connected. For a list of compatible
phones:

•

U.S.: Visit www.handsfreelink.com/Acura, or call 1-
888-528-7876.

•

Canada: For more information on smartphone
compatibility, call 1-888-528-7876.

19 ACURA TLX-31TZ36400.book 350 ページ２０１８年２月１６日　金曜日　午後１２時２２分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

351

Bluetooth® HandsFreeLink®

HFL Menus

Features

■

Making a call to a sender

1. Go to the text message screen.

The system automatically starts reading
the message aloud.

2 Displaying text messages P. 348

2. Rotate

to select Call, then press

19 ACURA TLX-31TZ36400.book 351 ページ２０１８年２月１６日　金曜日　午後１２時２２分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

352

Features

Compass

When you set the power mode to ON, the compass self-calibrates, and the compass
display appears.

Compass Calibration

If the compass indicates the wrong direction, or the CAL indicator blinks, you need
to manually calibrate the system.
1. Set the power mode to ON.
2. On the top screen of any source, press and hold

for five seconds.

The display switches to the Compass Settings screen.

3. Rotate

select

Calibration, then press

4. When the display changes to Calibration Start, press

5. Drive the vehicle slowly in two circles.

The compass starts to show a direction after the calibration. The CAL indicator
goes off.

Compass

Compass operation can be affected under the
following conditions:

•

Driving near power lines or stations

•

Crossing a bridge

•

Passing a large vehicle, or driving near a large
object that can cause a magnetic disturbance

•

When accessories such as antennas and roof racks
are mounted by magnets

Compass Calibration

Calibrate the compass in an open area.

While setting the compass, press the BACK button to
cancel the setting mode and return to the previous
screen.

Models with navigation self-calibrate using GPS. The
compass in the multi-information display and the
direction arrow on the map screen (when Heading-
Up view selected) may not be in sync when first
starting the vehicle, but should correct themselves as
you drive.
If the compass in the multi-information display
continues to indicate an incorrect direction, please
see your Acura dealer.

Models with navigation system

* Not available on all models

19 ACURA TLX-31TZ36400.book 352 ページ２０１８年２月１６日　金曜日　午後１２時２２分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

353

Compass

Compass Zone Selection

Features

Compass Zone Selection

1. Set the power mode to ON.
2. On the top screen of any source, press and hold

for five seconds.

The display switches to the Compass Settings screen.

3. Rotate

to select Zone Adjust, then press

The display shows the current zone number the system is set to.

4. To change the zone, rotate

to select the zone number of your area (See Zone

Map), then press

6 7 8 9

10 11

Zone Map

Guam Island: Zone 8

Puerto Rico: Zone 11

Compass Zone Selection

The zone selection is done to compensate the
variation between magnetic north and true north.

If the calibration starts while the audio system is in
use, the display returns to normal after the calibration
is completed.

19 ACURA TLX-31TZ36400.book 353 ページ２０１８年２月１６日　金曜日　午後１２時２２分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

356

Driving

Before Driving

Driving Preparation

Check the following items before you start driving.

• Make sure there are no obstructions on the windows, door mirrors, exterior

lights, or other parts of the vehicle.

Remove any frost, snow, or ice.

Remove any snow on the roof, as this can slip down and obstruct your field of
vision while driving. If frozen solid, remove ice once it has softened.

When removing ice from around the wheels, be sure not to damage the wheel
or wheel components.

• Make sure the hood is securely closed.

If the hood opens while driving, your front view will be blocked.

• Make sure the tires are in good condition.

Check air pressures, and check for damage and excessive wear.

2 Checking and Maintaining Tires P. 493

• Make sure there are no people or objects behind or around the vehicle.

There are blind spots from the inside.

■

Exterior Checks

Exterior Checks

NOTICE

When doors are frozen shut, use warm water around
the door edges to melt any ice. Do not try to force
them open, as this can damage the rubber trim
around the doors. When done, wipe dry to avoid
further freezing.

Do not pour warm water into the key cylinder.
You will be unable to insert the key if the water
freezes in the hole.

Heat from the engine and exhaust can ignite
flammable materials left under the hood, causing a
fire. If you’ve parked your vehicle for an extended
period, inspect and remove any debris that may have
collected, such as dried grass and leaves that have
fallen or have been carried in for use as a nest by a
small animal. Also check under the hood for leftover
flammable materials after you or someone else has
performed maintenance on your vehicle.

19 ACURA TLX-31TZ36400.book 356 ページ２０１８年２月１６日　金曜日　午後１２時２２分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Continued

357

Before Driving

Driving Preparation

Driving

• Store or secure all items on board properly.

Carrying too much cargo, or improperly storing it, can affect your vehicle’s
handling, stability, stopping distance, and tires, and make it unsafe.

2 Maximum Load Limit P. 359

• Do not pile items higher than the seat height.

They can block your view and may be thrown forward in the event of sudden
braking.

• Do not place anything in the front seat footwells. Make sure to secure the floor

mat.

An object or unsecured floor mat can interfere with your brake and accelerator
pedal operation while driving.

• If you have any animals on board, do not let them move around in the vehicle.

They may interfere with driving and a crash could occur.

• Securely close and lock all doors and the trunk.

2 Locking/Unlocking the Doors from the Inside P. 145

• Adjust your seating position properly.

Adjust the head restraint, too.

2 Adjusting the Seats P. 180
2 Adjusting the Front and Rear Outer Head Restraint Positions P. 183

• Adjust the mirrors and steering wheel properly for your driving.

Adjust them while sitting in the proper driving position.

2 Adjusting the Mirrors P. 177
2 Adjusting the Steering Wheel P. 176

■

Interior Checks

Interior Checks

The headlight aim is set by the factory, and does not
need to be adjusted. However, if you regularly carry
heavy items in the trunk have the aiming readjusted
at a dealer or by a qualified technician.

19 ACURA TLX-31TZ36400.book 357 ページ２０１８年２月１６日　金曜日　午後１２時２２分

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Acura TLX (2019 year). Manual - part 22
