Acura MDX (2018 year). Manual - part 27

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

422

Features

■

To make a call using the imported
phonebook

1. Press the PHONE button.
2. Rotate

 to select Phonebook, then

press .

3. Rotate

 to select a contact name, then

press .

u

The phonebook is stored alphabetically.

4. Rotate

 to select a number, then press

.

u

Dialing starts automatically.

1

To make a call using the imported phonebook

You can call a stored voice-tagged speed dial
number, phonebook name, or number using voice
commands.

2 Speed Dial P. 413

You can use the keyboard on the On Demand Multi-
Use Display

TM

 for a partial match search.

You can use the keyboard on the On Demand Multi-
Use Display

TM

 for an alphabetical search.

Models with navigation system

Models without navigation system

18 ACURA MDX-31TZ56400.book  422 ページ  ２０１７年８月２３日　水曜日　午後４時１分

423

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

■

To make a call using a phone number

1. Press the PHONE button.
2. Rotate

 to select Dial, then press

.

3. Select a number.

u

Use the keyboard on the On Demand
Multi-Use Display

TM

 for entering

numbers.

4. Select .

■

To make a call using redial

1. Press the PHONE button.
2. Rotate

 to select Redial, then press

.

u

Dialing starts automatically.

18 ACURA MDX-31TZ56400.book  423 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

424

Features

■

To make a call using the call history

Call history is stored by All

*1

, Dialed,

Received, and Missed.
1. Press the PHONE button.
2. Rotate

 to select Call History, then

press .

3. Move

or

to

select

All

*1

, Dialed,

Received, and Missed.

4. Rotate

 to select a number, then press

.

u

Dialing starts automatically.

1. Press the

 button.

2. Move the left selector wheel right to select

Call History.

3. Roll the left selector wheel to select a

number.

4. Push the left selector wheel or the



button.

u

Dialing starts automatically.

*1: This function may not be available depending on a cellular phone.

1

To make a call using the call history

The call history displays the last 20 dialed, received, or
missed calls.
(Appears only when a phone is connected to HFL.)

These icons next to the number indicate the
following:

: Dialed calls.
: Received calls.
: Missed calls.

The call history displays the last 12 dialed, received, or
missed calls.

Steering switches

On MID

Steering switches

18 ACURA MDX-31TZ56400.book  424 ページ  ２０１７年８月２３日　水曜日　午後４時１分

Continued

425

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

To make a call using a speed dial entry

1. Press the PHONE button.
2. Rotate

to

select

Speed Dial, then press

.

3. Rotate

 to select a number, then press

.

u

Dialing starts automatically.

1. Press the

 button.

2. Move the left selector wheel left to select

Speed Dial.

3. Roll the left selector wheel to select a

number.

4. Push the left selector wheel or the



button.

u

Dialing starts automatically.

1

To make a call using a speed dial entry

Rotate

 to select More Speed Dials to view

another paired phone’s speed dial list. You can make
a call from that list using the currently connected
phone.

When a voice tag is stored, press the

 button to

call the number using the voice tag.

2 Speed Dial P. 413

Any voice-tagged speed dial entry, phonebook name
or number can be dialed by voice from any screen.
Press the

 button and follow the prompts.

The speed dial displays the 20 speed dial entries.

Steering switches

On MID

Steering switches

18 ACURA MDX-31TZ56400.book  425 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

426

Features

When there is an incoming call, an audible
notification sounds (if activated) and the
Incoming Call screen appears.

Press the

 button to answer the call.

Press the

 button to decline or end the

call.

■

Receiving a Call

1

Receiving a Call

Call Waiting

Press the

 button to put the current call on hold to

answer the incoming call.

Press the

 button again to return to the current

call.
Ignore the incoming call if you do not want to answer
it.
Press the

 button if you want to hang up the

current call.

Information Screen

On Demand Multi-Use Display

TM

18 ACURA MDX-31TZ56400.book  426 ページ  ２０１７年８月２３日　水曜日　午後４時１分

Continued

427

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

The following options are available during a call.

Phone Call Active - Transfer to Mobile:
Transfer a call from HFL to your phone.

Mute: Mute your voice.
Transfer to Mobile: Transfer a call from HFL
to your phone.
Touch Tones: Send numbers during a call.
This is useful when you call a menu-driven
phone system.

The available options are shown on the On
Demand Multi-Use Display

TM

.

Select the option.

u

The Mute icon is checked when Mute is
selected. Select Mute again to turn it off.

■

Options During a Call

1

Options During a Call

Touch Tones: Available on some phones.

Information Screen

On Demand Multi-Use Display

TM

Mute Icon

Information Screen

On Demand Multi-Use Display

TM

18 ACURA MDX-31TZ56400.book  427 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

428

Features

HFL can display newly received text and e-mail messages as well as 20 of the most
recently received messages on a linked cell phone. Each received message can be
read aloud and replied to using a fixed common phrase.

1. A pop-up appears and notifies you of a new

text or e-mail message.

2. Rotate

 to select Read to listen to the

message, then press

.

u

The text or e-mail message is displayed.
The system automatically starts reading
out the message.

3. To discontinue the message read-out, press

.

■

Receiving a Text/E-mail Message

1

Receiving a Text/E-mail Message

The system does not display any received messages
while you are driving. You can only hear them read
aloud.

With some phones, you may be able to display up to
20 most recent text and e-mail messages.

State or local laws may limit your use of the HFL text/
e-mail message feature. Only use the text/e-mail
message feature when conditions allow you to do so
safely.

When you receive a text or e-mail message for the
first time since the phone is paired to HFL, you are
asked to turn the New Text/Email Alert setting to
On.

2 To turn on or off the text/e-mail message

notice P. 406

18 ACURA MDX-31TZ56400.book  428 ページ  ２０１７年８月２３日　水曜日　午後４時１分

Continued

429

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

If a paired phone has text message or mail accounts, you can select one of them to
be active and receive notifications.

1. Press the SETTINGS button.
2. Rotate

 to select Bluetooth/Phone

Settings, then press

.

u

Repeat the procedure to select Select
Account.

3. Rotate

 to select Text Messages or an

e-mail account you want, then press

.

■

Selecting a Mail Account

1

Selecting a Mail Account

You can also select a mail account from the folder list
screen or the message list screen.
Rotate

 to select Select Account, then press

.

You can only receive notifications from one text
message or mail account at a time.

18 ACURA MDX-31TZ56400.book  429 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

430

Features

■

Displaying text messages

1. Press the PHONE button.
2. Rotate

 to select Text/Email, then press

.

u

Select account if necessary.

3. Rotate

 to select a message, then press

.

u

The text message is displayed. The
system automatically starts reading the
message aloud.

4. Rotate

 to select View Full Message.

5. Press

 to displays the full text of the

message.

■

Displaying Messages

1

Displaying Messages

The

 icon appears next to an unread message.

If you delete a message on the phone, the message
will also be deleted from the system. If you send a
message from the system, the message goes to your
phone’s outbox.

To see the previous or next message, move

 or



on the text message screen.

Message List

Text Message

18 ACURA MDX-31TZ56400.book  430 ページ  ２０１７年８月２３日　水曜日　午後４時１分

Continued

431

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

Displaying e-mail messages

1. Press the PHONE button.
2. Rotate

 to select Text/Email, then press

.

3. Rotate

 to select a folder, then press

.

4. Rotate

 to select a message, then press

.

u

The e-mail is displayed. The system
automatically starts reading the message
aloud.

5. Rotate

 to select View Full Message.

6. Press

 to displays the full text of the

message.

1

Displaying e-mail messages

Received text and e-mail messages may appear in the
message list screen at the same time. In this case, text
messages are titled No Subject.

Folder List

Message List

E-mail
Message

18 ACURA MDX-31TZ56400.book  431 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

432

Features

■

Read or stop reading a message

1. Go to the text or e-mail message screen.

u

The system automatically starts reading
the message aloud.

2 Displaying Messages P. 430

2. Rotate

 to select Stop Reading

Messages.

3. Press

 to stop reading.

Press

 again to start reading the message

from the beginning.

■

Reply to a message

1. Go to the text or e-mail message screen.

u

The system automatically starts reading
the message aloud.

2 Displaying Messages P. 430

2. Rotate

 to select Reply, then press

.

3. Rotate

 to select the reply message, then

press .

u

Message sent appears on the screen
when the reply message was successfully
sent.

1

Reply to a message

The available fixed reply messages are as follows:

•

Talk to you later, I’m driving.

•

I’m on my way.

•

I’m running late.

•

OK

•

Yes

•

No

You cannot add, edit, or delete reply messages.

Only certain phones receive and send messages when
paired and connected. For a list of compatible
phones:

•

U.S.: Visit www.handsfreelink.com/Acura, or call 1-
888-528-7876.

•

Canada: For more information on smartphone
compatibility, call 1-888-528-7876.

18 ACURA MDX-31TZ56400.book  432 ページ  ２０１７年８月２３日　水曜日　午後４時１分

433

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

■

Making a call to a sender

1. Go to the text message screen.

u

The system automatically starts reading
the message aloud.

2 Displaying text messages P. 430

2. Rotate

 to select Call, then press

.

18 ACURA MDX-31TZ56400.book  433 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

434

Features

Provides a nationwide service for unexpected incidents. You can call for assistance
using a phone paired and connected to Bluetooth® HandsFreeLink®.

1. Press the PHONE button.
2. Rotate

 to select Roadside Assistance,

then press

.

3. Rotate

 to select a phone number, then

press .

u

Dialing starts automatically.

■

Roadside Assistance

*

1

Roadside Assistance

*

If you are subscribed to a paid AcuraLink package,
you can call roadside assistance using the LINK
button instead of your phone.

2 AcuraLink®

*

 P. 435

* Not available on all models

18 ACURA MDX-31TZ56400.book  434 ページ  ２０１７年８月２３日　水曜日　午後４時１分

435

Continued

Features

AcuraLink®

*

Is a subscription-based service that provides convenient features such as voice
communication in case of emergency, online security, one-on-one operator
assistance, and the transmission of important messages regarding your vehicle’s
status.

For information on traffic rerouting and traffic information updates, provided by the
AcuraLink server, see the Navigation System Manual.

■

Automatic collision notification

If your vehicle’s airbags deploy or if the unit
detects that the vehicle is severely impacted,
your vehicle will automatically attempt to
connect to the AcuraLink operator. Once
connected, information about your vehicle, its
positioning, and its condition will be sent to
the operator; you also can speak to the
operator when connected.

■

In Case of Emergency

1

AcuraLink®

*

AcuraLink also provides services you can operate
from the Internet or your smartphone.

To subscribe to AcuraLink, or to get more
information about all of its features, contact an Acura
dealer, or visit owners.acura.com (U.S.) or
www.acura.ca/owners/acuralink (Canada).

Canadian models

1

In Case of Emergency

Your vehicle may not be able to connect to the operator
if the battery level is low, the line is disconnected, or you
do not have adequate cellular coverage.

You cannot use emergency services when:

•

You travel outside the AcuraLink service coverage
areas.

•

There is a problem with the connecting devices,
such as the ASSIST button, microphone, speakers,
or the unit itself.

•

You are not subscribed to the service or your
subscription is no longer valid.

You cannot operate other navigation or phone
related functions using the screens while talking to
the operator.
Only the operator can terminate the connection to
your vehicle.

1

Automatic collision notification

If the unit fails to connect to the operator, it
repeatedly tries until it succeeds.

Information screen

On Demand Multi-Use Display

TM

When connected to the AcuraLink
operator:

* Not available on all models

18 ACURA MDX-31TZ56400.book  435 ページ  ２０１７年８月２３日　水曜日　午後４時１分

uu

AcuraLink®

*

u

436

Features

■

Manual operator connection

If you need to talk to the AcuraLink operator
in an emergency situation, you can manually
connect to them by pressing the ASSIST
button with the power mode in ACCESSORY
or ON.
1. Open the cover attached to the ceiling

console.

2. Press the ASSIST button.

u

You are connected to the AcuraLink
operator.

1

Manual operator connection

Do not press the button while driving. When you
need to contact the operator, park the vehicle in a
safe place.

If the unit fails to connect to the operator, it
automatically cancels the action after three minutes.

In an emergency, the cover can be broken through to
press the ASSIST button.

ASSIST Button

18 ACURA MDX-31TZ56400.book  436 ページ  ２０１７年８月２３日　水曜日　午後４時１分

Continued

437

uu

AcuraLink®

*

u

Features

Your subscribed telematics service provider can track your vehicle’s location,
remotely lock or unlock doors, and help you find your vehicle.
To use these features, you need your user ID and personal identification number
(PIN).

■

Stolen vehicle tracking

This feature searches and tracks down your vehicle position even if it is on the move.
If you believe that your vehicle has been stolen, contact the police as well as the
provider.

■

Remote door lock/unlock

The provider can remotely lock or unlock doors upon your request.

■

Vehicle finder

This feature is convenient to use when trying to locate your vehicle in large areas,
such as a crowded parking lot. If you cannot locate your vehicle after using the
remote transmitter’s answerback function, you can contact the provider which can
then flash your vehicle’s exterior lights and sound the horn.

■

Security alarm notification

If the security system in your vehicle detects an abnormal condition, such as
someone tampering with the lock on your vehicle, the provider notifies you by your
preferred method.

■

Security Features

1

Security Features

The contact information of your provider, your user
ID and PIN will be given when you subscribe to
AcuraLink. If you forget any of the above, contact a
dealer, or visit owners.acura.com (U.S.) or
www.acura.ca/owners/acuralink (Canada).

You can also activate the remote door lock/unlock
and vehicle finder features from the Internet or using
your smartphone app. Ask a dealer, or visit
owners.acura.com (U.S.) or www.acura.ca/owners/
acuralink (Canada) for details.

1

Vehicle finder

The lights will stop flashing and horn will stop
sounding under the following conditions:

•

When 30 seconds have elapsed.

•

You unlock the doors using the remote transmitter.

•

You unlock the doors using the keyless access
system.

•

You unlock the doors using the built-in key.

•

The power mode is set to ACCESSORY or ON.

18 ACURA MDX-31TZ56400.book  437 ページ  ２０１７年８月２３日　水曜日　午後４時１分
