358

Features

Customized Features

Use the information screen and On Demand Multi-Use Display

TM

 to customize

certain features.

■

How to customize

Select your desired setting item by pressing the SETTINGS button, then rotating



while the power mode is ON and the vehicle is at a complete stop. Press

.

1

Customized Features

When you customize settings, make sure that the
vehicle is at a complete stop and transmission is put
into

(

P.

To customize other features, rotate

, move

,  ,

 or  , and press

.

2 List of customizable options P. 365

Information Screen

1

How to customize

The following settings can be customized on the On
Demand Multi-Use Display

TM

.

•

Edit Source Order

•

Sound Settings

•

Edit/Delete HDD Music

*

•

Audio Settings

•

Screen Settings

•

RES Settings

*

2 How to customize P. 381

Information Screen

Information Screen

SETTINGS Button

* Not available on all models

18 ACURA MDX-31TZ56400.book  358 ページ  ２０１７年８月２３日　水曜日　午後４時１分

359

uu

Customized Features

u

Continued

Features

■

Customization flow

Information Screen

Press the SETTINGS button.



Bluetooth

Bluetooth

Bluetooth Device List

Edit Speed Dial

Auto Transfer

Auto Answer

Ring Tone

Automatic Phone Sync

Use Contact Photo

Enable Text/Email

Select Account

New Text/Email Alert



Text/Email





Message Auto Reading

*

Default

Edit Pairing Code

Phone





Bluetooth/

Phone

Settings





See the Navigation System Manual.



Navigation

Settings

*

* Not available on all models

18 ACURA MDX-31TZ56400.book  359 ページ  ２０１７年８月２３日　水曜日　午後４時１分

360

uu

Customized Features

u

Features





Camera

Settings

Fixed Guideline



Dynamic Guideline



Fixed Guideline

Dynamic Guideline



Camera

Settings

*1

Default

*1 : Models without cross traffic monitor
*2 : Models with cross traffic monitor and multi-view rear camera
*3 : Models with surround view camera system

Default



Camera

Settings

*2







Surround

View

Camera

Auto Show Camera after Reverse



Default Camera Mode in Forward

Default



Camera

Settings

*3



Default Camera Mode in Reverse

Show Camera When Decelerating

Clear Parking Guidance Automatically

Display

Fixed Guideline

Dynamic Guideline

Cross Traffic Monitor

Cross Traffic Monitor

Cross Traffic Monitor

Cross Traffic Monitor

18 ACURA MDX-31TZ56400.book  360 ページ  ２０１７年８月２３日　水曜日　午後４時１分

361

uu

Customized Features

u

Continued

Features

“Trip A” Reset Timing

“Trip B” Reset Timing



Language Selection

Adjust Outside Temp. Display







Forward Collision Warning Distance

ACC Forward Vehicle Detect Beep



Turn by Turn Display

*

Default

Meter

Driver

Assist

Lane Keeping Assist Suspend Beep

Blind Spot Info

*



Driving

Position

Road Departure Mitigation Setting

ACC Display Speed Unit

Memory Position Link

Auto Engine Idle Stop Guidance Screens

*



Easy Entry/Exit

Reverse Alert Tone



Vehicle

Settings

* Not available on all models

18 ACURA MDX-31TZ56400.book  361 ページ  ２０１７年８月２３日　水曜日　午後４時１分

362

uu

Customized Features

u

Features



Maintenance Reset

Maintenance Info.



Preferred Dynamic Mode

Dynamic

Mode



Key And Remote Unlock Mode

Keyless Lock Answer Back

Security Relock Timer

Auto Door Lock

Auto Door Unlock





Door

Auto Folding Door Mirror

*

Door Unlock Mode

Keyless Access Beep





Interior Light Dimming Time

Headlight Auto Off Timer

Auto Light Sensitivity

Remote Start System On/Off

*

Walk Away Auto Lock



Lighting



Keyless

Access

Keyless Access Light Flash



Keyless Open Mode

Power Open By Outer Handle



Power

Tailgate

* Not available on all models

18 ACURA MDX-31TZ56400.book  362 ページ  ２０１７年８月２３日　水曜日　午後４時１分

363

uu

Customized Features

u

Continued

Features

Auto Time Zone

*





Clock/Wallpaper Type

Clock Adjustment

Clock

Settings

Clock Format

Default

Auto Daylight

*

Clock Reset



AcuraLink Msg Notice

Delete AcuraLink Messages

AcuraLink

Settings

*

AcuraLink Subscription Status

Default



* Not available on all models

18 ACURA MDX-31TZ56400.book  363 ページ  ２０１７年８月２３日　水曜日　午後４時１分

364

uu

Customized Features

u

Features



Voice Prompt

Brightness

Contrast

Black Level





Default

Display

System

Settings

Voice
Reco.

Sync Display Brightness

System Device Information

*

Header Clock Display





Language

Operation Restriction Tips

*

Others



Default

Apple CarPlay Device List

Android Auto Device List



Smartphone

Settings

Smartphone Volume





Factory Data Reset

Units

*

Song By Voice

*

Song By Voice Phonetic Modification

*

Phonebook Phonetic Modification

*

Guidance Volume

*







Feedback

*

Guidance Volume

Verbal Reminder

* Not available on all models

18 ACURA MDX-31TZ56400.book  364 ページ  ２０１７年８月２３日　水曜日　午後４時１分

365

uu

Customized Features

u

Continued

Features

■

List of customizable options

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Bluetooth/
Phone
Settings

Default

Cancels/Resets all customized items in the
Bluetooth/Phone Settings group as default.

Yes/No

Bluetooth

Bluetooth

Turns the Bluetooth® on and off.

On

*1

/Off

Bluetooth Device List

Pairs a new phone to HFL, edits or deletes a
paired phone, or creates a security PIN.

2 Phone Setup P. 401

—

Edit Pairing Code

Changes a pairing code.

2 To change the pairing code setting P. 403

Random/Fixed

*1

Phone

Edit Speed Dial

Edits, adds or deletes a speed dial entry.

2 Phone Setup P. 401

—

Auto Transfer

Sets calls to automatically transfer from your
phone to HFL when you enter the vehicle.

On

*1

/Off

Auto Answer

Sets whether to automatically answer an
incoming call after about four seconds.

On/Off

*1

Information Screen

18 ACURA MDX-31TZ56400.book  365 ページ  ２０１７年８月２３日　水曜日　午後４時１分

366

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Bluetooth/
Phone
Settings

Phone

Ring Tone

Selects the ring tone.

Fixed/Mobile
Phone

*1

/Off

Automatic Phone Sync

Sets a phonebook data to be automatically
imported when a phone is paired to HFL.

On/Off

Use Contact Photo

Displays a caller’s picture on an incoming call
screen.

On

*1

/Off

Text/Email

Enable Text/Email

Turns the text/e-mail message function on and
off.

On

*1

/Off

Select Account

Selects a mail or text message account.

—

New Text/Email Alert

Selects whether a pop-up alert comes on the
screen when HFL receives a new text message/E-
mail.

—

Message Auto Reading

*

Selects whether the system automatically reads
out messages, and, if selected, whether only
when driving.

On

*1

/Off

* Not available on all models

18 ACURA MDX-31TZ56400.book  366 ページ  ２０１７年８月２３日　水曜日　午後４時１分

367

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Camera
Settings

Default

Cancels/Resets all customized items in the
Camera Settings group as default.

Yes/No

Fixed Guideline

Selects whether the fixed guidelines come on the
rear camera monitor.

On

*1

/Off

Dynamic Guideline

Selects whether the dynamic guidelines come on
the rear camera monitor.

On

*1

/Off

Camera
Settings

Default

Cancels/Resets all customized items in the
Camera Settings group as default.

Yes/No

Rear
Camera

Fixed Guideline

Selects whether the fixed guidelines come on the
rear camera monitor.

On

*1

/Off

Dynamic Guideline

Selects whether the dynamic guidelines come on
the rear camera monitor.

On

*1

/Off

Cross
Traffic
Monitor

Cross Traffic Monitor

Turns the cross traffic monitor feature on and off.

On

*1

/Off

Models
without
cross traffic
monitor

Models with
cross traffic
monitor and
multi-view
rear camera

18 ACURA MDX-31TZ56400.book  367 ページ  ２０１７年８月２３日　水曜日　午後４時１分

368

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Camera
Settings

Default

Cancels/Resets all customized items in the
Camera Settings group as default.

Yes/No

Surround
View
Camera

Fixed Guideline

Sets whether to turn on the reference line
display.

On

*1

/Off

Dynamic Guideline

Sets whether to turn on the projection line
display.

On

*1

/Off

Auto Show Camera
after Reverse

Sets the rear view to be automatically switched to
the front view when the transmission is out of

(

R.

On/Off

*1

Default Camera Mode in
Forward

Sets which screen to display when the surround
view camera system is turned on while the
vehicle is moving forward.

 (Front Ground

View)

*1

/Last Used/



(Front Wide View)/



(Side View)

Default Camera Mode in
Reverse

Sets which screen to display when the surround
view camera system is turned on while the
vehicle is reversing.

 (Rear Ground

View)

*1

/Last Used/



(Rear Normal View)/

 (Rear Wide View)

Show Camera When
Decelerating

Sets the screen to automatically return to the
camera view at vehicle speeds of 7 mph (12
km/h) or lower.

On/Off

*1

Models with
surround
view camera
system

18 ACURA MDX-31TZ56400.book  368 ページ  ２０１７年８月２３日　水曜日　午後４時１分

369

uu

Customized Features

u

Continued

Features

*1:Default Setting
*2:Appears only when frontal camera view is displayed.

Setup

Group

Customizable Features

Description

Selectable Settings

Camera
Settings

Surround
View
Camera

Clear Parking Guidance
Automatically

Turns the parking guide lines on and off.

On

*1

/Off

Display

*2

Adjusts the screen’s preferences.

—

Cross
Traffic
Monitor

Cross Traffic Monitor

Turns the cross traffic monitor feature on and off.

On

*1

/Off

Models with
surround
view camera
system

18 ACURA MDX-31TZ56400.book  369 ページ  ２０１７年８月２３日　水曜日　午後４時１分

370

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle
Settings

Default

Cancels/Resets all customized items in the
Vehicle Settings group as default.

Yes/No

Driver
Assist

Forward Collision
Warning Distance

Changes at which distance CMBS

TM

 alerts.

Long/Normal

*1

/Short

ACC Forward Vehicle
Detect Beep

Causes the system to beep when the system
detects a vehicle, or when the vehicle goes out of
the ACC with LSF range.

On/Off

*1

ACC Display Speed Unit

Changes the speed unit for ACC with LSF on the
MID.

mph

*1

/km/h (U.S.)

mph/km/h

*1

 (Canada)

Road Departure
Mitigation Setting

Changes the setting for the road departure
mitigation system.

Normal

*1

/Wide/

Warning Only

Lane Keeping Assist
Suspend Beep

Causes the system to beep when the LKAS is
suspended.

On/Off

*1

Blind Spot Info

*

Changes the setting for the blind spot
information.

Audible And Visual
Alert

*1

/Visual Alert/

Off

* Not available on all models

18 ACURA MDX-31TZ56400.book  370 ページ  ２０１７年８月２３日　水曜日　午後４時１分

371

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle
Settings

Meter

Language Selection

Changes the displayed language on the MID.

English

*1

/Français/

Español

Adjust Outside Temp.
Display

Adjusts the temperature reading by a few
degrees.

-5°F ~ ±0°F

*1

 ~ +5°F

(U.S.)
-3°C ~ ±0°C

*1

 ~ +3°C

(Canada)

“Trip A” Reset Timing

Changes the setting of how to reset trip meter A,
average fuel economy A, average speed A, and
elapsed time A.

When Refueled/IGN
Off/Manually Reset

*1

“Trip B” Reset Timing

Changes the setting of how to reset trip meter B,
average fuel economy B, average speed B, and
elapsed time B.

When Refueled/IGN
Off/Manually Reset

*1

Reverse Alert Tone

Causes the beeper to sound once when the
transmission is put into

(

R.

On

*1

/Off

Auto Engine Idle Stop
Guidance Screens

*

Selects whether the Auto Idle Stop display comes
on.

On/Off

*1

Turn by Turn Display

*

Selects whether the turn-by-turn display comes
on during the route guidance.

On

*1

/Off

* Not available on all models

18 ACURA MDX-31TZ56400.book  371 ページ  ２０１７年８月２３日　水曜日　午後４時１分

372

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle
Settings

Driving
Position

Memory Position Link

Turns the driving position memory system on and
off.

On

*1

/Off

Easy Entry/Exit

Moves the seat fully rearward and steering wheel
fully up when you get in/get out of the vehicle.
Changes the setting for this feature.

Seat & Steering
Wheel

*1

/Seat Only/

Steering Wheel
Only/Off

Keyless
Access

Door Unlock Mode

Changes which doors unlock when you grab the
driver’s door handle.

Driver’s Door or
Tailgate Only

*1

/All

Doors

Keyless Access Light
Flash

Causes some exterior lights to flash when you
unlock/lock the doors.

On

*1

/Off

Keyless Access Beep

Causes the beeper to sound when you unlock/
lock the doors.

On

*1

/Off

Remote Start System
On/Off

*

Turns the remote engine start feature on and off.

On

*1

/Off

Walk Away Auto Lock

Changes the settings for the automatic locking
the doors when you walk away from the vehicle
while carrying the keyless access remote.

On/Off

*1

* Not available on all models

18 ACURA MDX-31TZ56400.book  372 ページ  ２０１７年８月２３日　水曜日　午後４時１分

373

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle
Settings

Lighting

Interior Light Dimming
Time

Changes the length of time the interior lights stay
on after you close the doors.

60seconds/
30seconds

*1

/

15seconds

Headlight Auto Off
Timer

Changes the length of time the exterior lights
stay on after you close the driver’s door.

60seconds/
30seconds/
15seconds

*1

/

0seconds

Auto Light Sensitivity

Changes the timing for the headlights to come
on.

Max/High/Mid

*1

/

Low/Min

18 ACURA MDX-31TZ56400.book  373 ページ  ２０１７年８月２３日　水曜日　午後４時１分
